Product Details:
|
Brand: | Samsung | Diagonal Size: | 46" |
---|---|---|---|
Resolution: | 1920(RGB)×1080, FHD 47PPI | Luminance: | 2500 Cd/m² |
Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Max. Ratings: | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
Active Area: | 1018.08(W)×572.67(H) Mm | Outline Dim.: | 1035.9(H)×590.5(V)×87.1(D) Mm |
Power Supply: | 12.0V (Typ.) | Bezel Opening: | 1020.1(W)×574.7(H) Mm |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 1018.08(W)×572.67(H) mm, outline size of 1035.9(W)×590.5(H)×87.1(D) mm, viewing area size of 1020.1(W)×574.7(H) mm, with surface treament of Glare (Haze 0%), Hard coating (3H), net weight of 11.0/12.0Kgs (Typ./Max.). As a SVA, Normally Black, Transmissive LCM product, LTI460HF01 can provides 2500 cd/m² display brightness 5000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 6 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Direct light type and have a working life time of 50K hours, With LED Driver. LTI460HF01 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 92 pins Connector with power supply voltage of 12.0V (Typ.).
