Product Details:
|
| Brand: | BOE | Diagonal Size: | 23.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 95PPI | Brightness: | 250 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Basic Info : | |
|---|---|
| Reliability : |
| Pixel Features : | |
|---|---|
| Mechanical Size : | |
| Outline Features : | |
| Holes & Brackets : | |
| Other Features : |
| Basic Information : | |
|---|---|
| Color Performance : | |
| 1931 Color Gamut : |
| Back-light Features : | |
|---|---|
| Lamp Electrical : | |
| Interface Features : | |
| Interface Detail : |
| Signal Systerm : | |
|---|---|
| Signal Electrical : | |
| Interface Features : | |
| Connector Detail : |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 509.184(W)×286.416(H) mm, outline size of 517.2(W)×302.8(H)×12.7(D) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 2.10Kgs (Typ.). As a ADS, Normally Black, Transmissive LCM product, MV230FHM-N20 can provides 250 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 14 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted 18S3P WLED as it's backlight systerm which was placed as Edge light type (Bottom side) and have a working life time of 30K hours, external backlight driver is additionally needed. MV230FHM-N20 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.).
