Product Details:
|
Brand: | CSOT | Diagonal Size: | 15.6" |
---|---|---|---|
Resolution: | 2560(RGB)×1440, Quad-HD 188PPI | Brightness: | 350 Cd/m² |
Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10 |
Basic Information : | |
---|---|
Environment : |
Pixel Features : | |
---|---|
Mechanical Size : | |
Outline Features : | |
Mounting : | |
Other Spec : |
Basic Information : | |
---|---|
Color Performance : | |
1931 Color Gamut : |
Signal Electrical : | |
---|---|
Signal Type : | |
Interface Features : | |
Interface Detail : |
Backlight Features : | |
---|---|
Interface Features : | |
Backlight Driver : | |
Driver Electrical : |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 344.22(W)×193.62(H) mm, outline size of 350.66(W)×214.72(H)×2.6(D) mm, with surface treament of Antiglare, Reflection 6.5% (Max.), net weight of 290g (Max.), shape stype of Slim (PCBA Flat, T≤3.2mm). As a FFS, Normally Black, Transmissive LCM product, MNF601CA1-3 can provides 350 cd/m² display brightness 1200:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10 (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 9 (Typ.)(Tr+Td), 3 (Typ.)(G to G)(OD) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 100% (sRGB). This product adopted 10S5P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, With LED Driver. MNF601CA1-3 utilizes eDP (4 Lanes) as it's signal inputting systerm, which connected by 40 pins Connector with power supply voltage of 3.3V
