Product Details:
|
| Brand: | LG Display | Diagonal Size: | 55" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 40PPI | Brightness: | 500 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Min.)(CR≥10) | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Basic Information : | Brand | Model | LD550DUN-WPA2 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 55" | Alias | LD550DUN (WP)(A2) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.210×0.630 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.630×0.630 (H×V) [40PPI] | |
| Mechanical Size : | Active Area(mm) | 1209.6(H) × 680.4(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 1212.2(H) × 683(V) | Depth(mm) | 38.5/55.2 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape / Portrait | |
| Videowall Seam : | 2.6 mm (Active to Active) | |||
| Other Spec : | Weight | 13.8/15.2Kgs (Typ./Max.) | Treatment | Antiglare (Haze 28%), Hard coating (2H) |
| Basic Information : | Luminance(cd/m²) | 500 (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Display Mode | S-IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 8 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.279; Y:0.292 | Display Colors | 1.06B (8-bit + Dithering) |
| Color Temperature | 9972K | White Uniformity | 1.11/1.25 (Typ./Max.)(9 points) | |
| 1931 Color Gamut : | NTSC Ratio | 71% | sRGB | 98% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 74% coverage | |
| Rec.2020 | 53% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 580/750mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 7.0/9.1W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8/10-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Direct light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 100K(Typ.) (Hours) | |
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | 20022WR-14B2 | 1 pcs | 14 pins | 2.0 mm | ||
| YEONHO | 20022WR-12B2 | 1 pcs | 12 pins | 2.0 mm | ||
| Backlight Driver : | With LED Driver | |||||
| Driver Electrical : | Voltage Supply | 24.0±2.4V | Current Supply | 5.92/6.42A (Typ./Max.) | ||
| Consumption | 142/154W (Typ./Max.) | |||||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 1209.6(W)×680.4(H) mm, outline size of 1212.2(W)×683(H)×55.2(D) mm, with surface treament of Antiglare (Haze 28%), Hard coating (2H), net weight of 13.8/15.2Kgs (Typ./Max.), active_to_active splicing seam 2.6 mm. As a S-IPS, Normally Black, Transmissive LCM product, LD550DUN-WPA2 can provides 500 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit + Dithering gray scale signal for each dot, thus presenting a palette of 1.06B colors, also with performance of color gamut 98% (sRGB). This product adopted WLED as it's backlight systerm which was placed as Direct light type and have a working life time of 100K hours, With LED Driver. LD550DUN-WPA2 utilizes LVDS (2 ch, 8/10-bit) as it's signal inputting systerm, which connected by 51 pins Connector with power supply voltage of 12.0V (Typ.)
