Product Details:
|
| Brand: | BOE | Diagonal Size: | 49" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 45PPI | Luminance: | 500 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Max. Ratings: | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Basic Info : | Panel Brand | Panel Model | DV490FHM-NV0 | |
|---|---|---|---|---|
| Diagonal Size | 49" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | 0 ~ 50 °C | Storage Temp. | -20 ~ 60 °C |
| Pixel Features : | Pixel Format | 1920(RGB)×1080 [FHD] | Dot Pitch | 0.1865×0.5595 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.5595×0.5595 mm (H×V) [45PPI] | |
| Mechanical Size : | Display Area | 1074.24×604.26 mm (H×V) | Bezel Area | 1074.54×604.56 mm (H×V) |
| Outline Dim. | 1078.34×608.36 mm (H×V) | Outline Depth | 40.2/59.67 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style | ||
| Holes & Brackets : | Rear mounting holes | |||
| Videowall Seam : | 4.1 mm (Active to Active) | |||
| Other Features : | Weight | 18.0Kgs (Typ.) | Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Basic Information : | Brightness | 500 cd/m² (Typ.) | Contrast Ratio | - |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Optical Mode | ADS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 8 (Typ.)(G to G) (ms) | |
| Color Performance : | Chromaticity | Wx:0.280; Wy:0.290 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 9969K | White Uniformity | 1.33 (Max.)(5 points) | |
| 1931 Color Gamut : | NTSC Ratio | 77% | sRGB | 98% coverage |
| Adobe RGB | 79% coverage | DCI-P3 | 80% coverage | |
| Rec.2020 | 58% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 30K(Typ.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Direct light type | |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| CviLux | CI0114M1HR0-NH | 2.0 mm | 14 pins | 1 pcs | ||
| Driver Electrical : | Voltage Input | 24.0±2.4V | Current Input | 6.5/7.2A (Typ./Max.) | ||
| Consumption | 140/155W (Typ./Max.) | |||||
| Signal Systerm : | LVDS (2 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | 560/950mA (Typ./Max.) | ||
| Consumption | 6.8/11.4W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| UJU | IS050-C51B-C39-S | 0.5 mm | 51 pins | 1 pcs | ||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 1074.24(W)×604.26(H) mm, outline size of 1078.34(W)×608.36(H)×59.67(D) mm, viewing area size of 1074.54(W)×604.56(H) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 18.0Kgs (Typ.), active_to_active splicing seam 4.1 mm. As a ADS, Normally Black, Transmissive LCM product, DV490FHM-NV0 can provides 500 cd/m² display brightness, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Direct light type and have a working life time of 30K hours, With LED Driver. DV490FHM-NV0 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 51 pins Connector with power supply voltage of 12.0V (Typ.)
