Product Details:
|
| Brand: | HKC | Diagonal Size: | 27.0" |
|---|---|---|---|
| Resolution: | 1920(RGB)×1080, FHD 81PPI | Brightness: | 0 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| SN270CU01-1 | a-Si TFT-LCD , CELL | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| 0 ~ 50 °C | -20 ~ 60 °C |
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 0 | 89/89/89/89 (Typ.)(CR≥10) | 12 (Typ.)(G to G) | |
| Best View on | Display Mode | Contrast Ratio | |
| Symmetry | FSA, Normally Black, Transmissive | 4000 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 6457K | 16.7M (8-bit) | X:0.315; Y:0.319 | |
| 1931 Color Gamut : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 73% | 96% | 74% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 76% | 55% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Transmissivity : | 4.6% (Typ.)(with Polarizer) | ||
| Panel Size : | 27.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 1920(RGB)×1080 [FHD] | RGB Vertical Stripe | 0.3114×0.3114 [81PPI] | 0.1038×0.3114 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 597.888(H) × 336.312(V) | - | 608.288(H) × 348.037(V) | 1.06 (Typ.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Plate Thickness |
| Curved Display, R1500 | Landscape type | 16:9 (H:V) | 0.38+0.38 mm | |
| Other Detail : | Weight | Panel Cover | Treatment | |
| 525g (Typ.) | - | Antiglare (Haze 25%), Hard coating (3H) | ||
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
|---|---|---|---|---|---|---|
| 12.0V (Typ.) | 0.41/0.53A (Typ./Max.) | 8.28/10.76W (Typ./Max.) | ||||
| Interface Features : | Position | Signal | Type | |||
| - | LVDS (4 ch, 8-bit) | Connector | ||||
| Connector Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| 21EJ0-110-0001_04 | 0.5 mm | 51 pins | 1 pcs | |||
| YEONHO | 12507WR-H10G | 1.25 mm | 10 pins | 1 pcs | ||
| Box Type | Pcs/Box | Box Qty | Package LWH (mm) | G.W (kgs) | Volume (m³) | Remarks |
| Box | 15 | 1 | 820×560×114 | 9.04 | 0.0523 | |
| Pallet | 270 | 18 | 1150×850×1046 | 178.50 | 1.0225 |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 597.888(W)×336.312(H) mm, outline size of 608.288(W)×348.037(H)×1.06(D) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 525g (Typ.), utilizing 0.38+0.38 mm mm plate. As a FSA, Normally Black, Transmissive CELL product, SN270CU01-1 can provides 4000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 12 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product have no backlight. SN270CU01-1 utilizes LVDS (4 ch, 8-bit) as it's signal inputting systerm, which connected by 61 pins Connector with power supply voltage of 12.0V (Typ.).
