Product Details:
|
| Brand: | LG Display | Diagonal Size: | 55" |
|---|---|---|---|
| Resolution: | 3840(RGB)×2160, UHD 80PPI | Brightness: | 0 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Min.)(CR≥10) | Environment: | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Basic Information : | Brand | Model | LC550EQC-SPA1 | |
|---|---|---|---|---|
| Type | CELL a-Si TFT-LCD | Used For | ||
| Screen Size | 55" | Alias | LC550EQC (SP)(A1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 3840(RGB)×2160, UHD | Dot Pitch(mm) | 0.105×0.315 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.315×0.315 (H×V) [80PPI] | |
| Mechanical Size : | Active Area(mm) | 1209.6(H) × 680.4(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 1221.4(H) × 694.8(V) | Depth(mm) | 1.2 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Glass Thickness | - |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 2.50/2.63Kgs (Typ./Max.) | Treatment | Antiglare (Haze 3%), Hard coating (2H), Antireflection |
| Basic Information : | Luminance(cd/m²) | 0 | Contrast Ratio | 1300:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 8/10 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | - | Display Colors | 1.07B (8-bit + Dithering) |
| 1931 Color Gamut : | NTSC Ratio | - | sRGB | 85% coverage |
| Adobe RGB | 70% coverage | DCI-P3 | 69% coverage | |
| Rec.2020 | 51% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | No | Transmissivity | 5.49% (Typ.)(with Polarizer) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.)(VLCD) | Current Supply | 930/1210mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | EPI | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| HRS | TF06L-60S-0.5SH | 2 pcs | 60 pins | 0.5 mm | ||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 1209.6(W)×680.4(H) mm, outline size of 1221.4(W)×694.8(H)×1.2(D) mm, with surface treament of Antiglare (Haze 3%), Hard coating (2H), Antireflection, net weight of 2.50/2.63Kgs (Typ./Max.). As a IPS, Normally Black, Transmissive CELL product, LC550EQC-SPA1 can provides 1300:1 transimissive contrast ratio, 89/89/89/89 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8/10 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit + Dithering gray scale signal for each dot, thus presenting a palette of 1.07B colors. This product have no backlight. LC550EQC-SPA1 utilizes EPI as it's signal inputting systerm, which connected by 120 pins Connector with power supply voltage of 12.0V (Typ.)(VLCD)
