Product Details:
|
| Brand: | OPTREX | Diagonal Size: | 5.2" |
|---|---|---|---|
| Resolution: | 240×64 47PPI | Luminance: | 400 Cd/m² |
| Viewing Angle: | 50/50/35/50 (Typ.)(CR≥2) | Environment: | Operating Temperature: 10 ~ 40 °C ; Storage Temperature: -20 ~ 60 °C |
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| DMF5010NB-FW | STN-LCD , LCM | DMF-5010NB-FW | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| 10 ~ 40 °C | -20 ~ 60 °C |
| Panel Size : | 5.2 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 240×64 | Rectangle | 0.53×0.53 mm | 0.53×0.53 mm [47PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 127.2×33.9 mm | 132.0×39.0 mm | 200×66 mm | 23.0 (Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | >3:1 (W : H) | Landscape type | ||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 250g (Max.) | |||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 400 cd/m² (Min.) | STN, Blue mode, Transmissive | 7:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 50/50/35/50 (Typ.)(CR≥2) | 6 o'clock | 70/260 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| - | Monochrome |
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 8.2mA (Typ.) | 5.0V (Typ.) | - | ||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| 1 pcs | 20 pins | |||||
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| CCFL | Edge light type | Straight | 1 pcs | 15K(Typ.) | - | |
| CCFL Electrical : | Current Input | Voltage Input | Consumption | |||
| 5.0±1mA | 270V (Typ.) | |||||
| Turn-on Voltage | Lamp Frequency | |||||
| 900V (Typ.) | ||||||
| Interface Features : | Position | Type | CCFL Driver | |||
| - | Connector | No | ||||
| Interface Detail | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| 1 pcs | 4 pins | BLL-4PINS-HNNL | ||||
whose pixels are arranged in Rectangle. As for mechanical detail, it features active area of 127.2(W)×33.9(H) mm, outline size of 200(W)×66(H)×2.3(D) mm, viewing area size of 132.0(W)×39.0(H) mm, net weight of 250g (Max.). As a STN, Blue mode, Transmissive LCM product, DMF5010NB-FW can provides 400 cd/m² display brightness 7:1 transimissive contrast ratio, 50/50/35/50 (Typ.)(CR≥2) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 70/260 (Typ.)(Tr/Td) ms., thus presenting a palette of Monochrome colors. This product adopted 1 pcs CCFL as it's backlight systerm which was placed as Edge light type and have a working life time of 15K hours, external backlight driver is additionally needed. DMF5010NB-FW utilizes 8-bit parallel as it's signal inputting systerm, which connected by 20 pins with power supply voltage of 5.0V (Typ.)
