Product Details:
|
| Brand: | LG Display | Diagonal Size: | 40" |
|---|---|---|---|
| Resolution: | 5120(RGB)×2160, WUHD 139PPI | Luminance: | 300 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) | Environment: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Basic Info : | Panel Brand | Panel Model | LM400RW1-SSA1 | |
|---|---|---|---|---|
| Diagonal Size | 40" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LM400RW1 (SS)(A1) | |
| Reliability : | Operating Temp. | 0 ~ 50 °C | Storage Temp. | -20 ~ 60 °C |
| RoHS State | Vibration Rating | 1.0G (9.8 m/s²) |
| Pixel Features : | Pixel Format | 5120(RGB)×2160 [WUHD] | Dot Pitch | 0.0605×0.1815 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.1815×0.1815 mm (H×V) [139PPI] | |
| Mechanical Size : | Display Area | 929.28×392.04 mm (H×V) | Bezel Area | - |
| Outline Dim. | 942.61×414.64 mm (H×V) | Outline Depth | 16.02 (Typ.) mm | |
| Outline Features : | Form Factor | Curved Display, R2500 | Orientation | Landscape type |
| Aspect Ratio | 21:9 (H:V) | Shape Style | 3-side borderless | |
| Holes & Brackets : | Rear mounting holes | |||
| Other Features : | Weight | 5.89/6.19Kgs (Typ./Max.) | Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Basic Information : | Brightness | 300 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 14 (Typ.)(G to G) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 1.07B (8-bit + Hi-FRC) |
| Color Temperature | 6485K | White Uniformity | 1.33 (Max.)(9 points) | |
| 1931 Color Gamut : | NTSC Ratio | 95% | sRGB | 100% coverage |
| Adobe RGB | 89% coverage | DCI-P3 | 96% coverage | |
| Rec.2020 | 71% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | 4 strings × 2CN | Lamp Type | WLED | Life Time | 30K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 15S4P×2CN | Position | Edge light type (Top side) | |
| Lamp Electrical : | Voltage Input | 44±3V | Current Input | 95/100mA (Typ./Max.) | ||
| Consumption | 33.4/35.7W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position |  |
Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| YEONHO | 10035WS-H06D | 1.0 mm | 6 pins | 2 pcs | BLE-6PINS-CCAACC | |
| Signal Systerm : | eDP (8 Lanes), HBR2 (5.4G/lane) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 10.0V (Typ.) | Current Input | 1.1/1.38A (Typ./Max.) | ||
| Consumption | 11.0/13.8W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| I-PEX | 20525-060E-01 | 0.4 mm | 60 pins | 1 pcs | ||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 929.28(W)×392.04(H) mm, outline size of 942.61(W)×414.64(H) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 5.89/6.19Kgs (Typ./Max.). As a IPS, Normally Black, Transmissive LCM product, LM400RW1-SSA1 can provides 300 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 14 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit + Hi-FRC gray scale signal for each dot, thus presenting a palette of 1.07B colors, also with performance of color gamut 96% (DCI-P3). This product adopted 15S4P×2CN WLED as it's backlight systerm which was placed as Edge light type (Top side) and have a working life time of 30K hours, external backlight driver is additionally needed. LM400RW1-SSA1 utilizes eDP (8 Lanes) as it's signal inputting systerm, which connected by 60 pins Connector with power supply voltage of 10.0V (Typ.)
