Product Details:
|
| Brand: | BOE | Diagonal Size: | 20.1" |
|---|---|---|---|
| Resolution: | 1600(RGB)×1200, UXGA 99PPI | Luminance: | 450 Cd/m² |
| Viewing Angle: | 89/89/89/89 (Typ.)(CR≥100) | Environment: | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -55 ~ 85 °C |
| Basic Info : | Panel Brand | Panel Model | TAD201-001 | |
|---|---|---|---|---|
| Diagonal Size | 20.1" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -30 ~ 80 °C | Storage Temp. | -55 ~ 85 °C |
| RoHS State | Vibration Rating | 1.5G (14.7 m/s²) |
| Pixel Features : | Pixel Format | 1600(RGB)×1200 [UXGA] | Dot Pitch | 0.085×0.255 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.255×0.255 mm (H×V) [99PPI] | |
| Mechanical Size : | Display Area | 408×306 mm (H×V) | Bezel Area | 411×309 mm (H×V) |
| Outline Dim. | 432×331.5 mm (H×V) | Outline Depth | 19.5±0.2 mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features : | Weight | 2.45Kgs (Typ.) | Surface | Antiglare (Haze 25%) |
| Basic Information : | Brightness | 450 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥100) | Optical Mode | ADS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 25 (Typ.)(Tr+Tf) (ms) | |
| Color Performance : | Chromaticity | Wx:0.302; Wy:0.329 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 7099K | White Uniformity | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamut : | NTSC Ratio | 68% | sRGB | 88% coverage |
| Adobe RGB | 71% coverage | DCI-P3 | 70% coverage | |
| Rec.2020 | 51% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | Array | Lamp Type | WLED | Life Time | 30K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 10S5P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 29/36V (Min./Max.) | Current Input | 120mA (Typ.) | ||
| Consumption | 17.4/21.6W (Min./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| 6 pins | 1 pcs | BLE-6PINS-ACCCCC | ||||
| Signal Systerm : | LVDS (2 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | - | ||
| Consumption | 4.8W (Typ.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FI-XB30SRL-HF11 | 1.0 mm | 30 pins | 1 pcs | ||
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 408(W)×306(H) mm, outline size of 432(W)×331.5(H)×19.7(D) mm, viewing area size of 411(W)×309(H) mm, with surface treament of Antiglare (Haze 25%), net weight of 2.45Kgs (Typ.). As a ADS, Normally Black, Transmissive LCM product, TAD201-001 can provides 450 cd/m² display brightness 800:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥100) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Tf) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 70% (NTSC). This product adopted 10S5P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 30K hours, external backlight driver is additionally needed. TAD201-001 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 12.0V (Typ.)
