Product Details:
|
| Brand: | LG Display | Diagonal Size: | 32.0" |
|---|---|---|---|
| Resolution: | 1366×768(RGB), WXGA 49PPI | Viewing Angle: | 89/89/89/89 (Min.)(CR≥10) |
| Luminance: | 0 Cd/m² | Power Supply: | 12.0V (Typ.) |
| Environment: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| LC320DXJ-SQA1 | a-Si TFT-LCD , CELL | - | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| 0 ~ 50 °C | -20 ~ 60 °C |
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 0 | 89/89/89/89 (Min.)(CR≥10) | 7/9 (Typ.)(Tr/Td) | |
| Best View on | Display Mode | Contrast Ratio | |
| Symmetry | IPS, Normally Black, Transmissive | 1200 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| - | 16.7M (6-bit + Dithering) | - | |
| 1931 Color Gamut : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 68% | 85% | 70% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 70% | 51% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Transmissivity : | 6.14% (Typ.)(with Polarizer) | ||
| Panel Size : | 32.0" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 1366×768(RGB) [WXGA] | RGB Horizontal Stripe | 0.51075×0.51075 [49PPI] | 0.51075×0.17025 | |
| Mechanical Size : | Active Area (mm) | Bezel Area (mm) | Outline Dimension (mm) | Outline Depth (mm) |
| 697.685(H) × 392.256(V) | - | 715(H) × 411(V) | 1.20 (Typ.) mm | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Plate Thickness |
| Flat Rectangle | Landscape type | 16:9 (H:V) | 0.50+0.50 mm | |
| Other Detail : | Weight | Panel Cover | Treatment | |
| 860/900g (Typ./Max.) | - | Antiglare (Haze 1%), Hard coating (2H) | ||
| Reverse Scan : | No |
|---|---|
| Vertical Frequency : | 60Hz |
| Driver IC : | COF Built-in 2 source chips |
| Panel Driving Electrical : | Voltage Supply | Current Supply | Power | |||
|---|---|---|---|---|---|---|
| 12.0V (Typ.) | 213/275mA (Typ./Max.) | 2.76/3.59 (Typ./Max.) | ||||
| Interface Features : | Position | Signal | Type | |||
| - | LVDS (1 ch, 8-bit) | Connector | ||||
| Connector Detail : | Brand | Model | Pin Pitch | Pin Amount | Quantity | Configuration |
| JAE | 10031HR-H30 | 1.0 mm | 30 pins | 1 pcs | ||
whose pixels are arranged in RGB Horizontal Stripe. As for mechanical detail, it features active area of 697.685(W)×392.256(H) mm, outline size of 715(W)×411(H)×1.2(D) mm, with surface treament of Antiglare (Haze 1%), Hard coating (2H), net weight of 860/900g (Typ./Max.), utilizing 0.50+0.50 mm mm plate. As a IPS, Normally Black, Transmissive CELL product, LC320DXJ-SQA1 can provides 1200:1 transimissive contrast ratio, 89/89/89/89 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 7/9 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit + Dithering gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 69% (NTSC). This product have no backlight. LC320DXJ-SQA1 utilizes LVDS (1 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 12.0V (Typ.).
