Product Details:
|
| MODEL NUMBER: | LD050WV1-SP01 | TEMPERATURE RANGE: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
|---|---|---|---|
| VIEWING ANGLEG: | 85/85/85/85 (Typ.)(CR≥10) | RESOLUTION: | 480(RGB)×800 (WVGA) 188PPI |
| Lamp Type: | WLED | BRIGHTNESS: | 500CD/M2 |
| SIZE: | 5.0"inch | BRAND: | LG DISPLAY |
| High Light: | 188PPI WVGA TFT LCD Panel,480×800 Symmetry TFT LCD Panel,500cd/m2 SRGB TFT LCD Display |
||
| Basic Info : | Panel Brand | Panel Model | LD050WV1-SP01 | |
|---|---|---|---|---|
| Diagonal Size | 5.0" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LD050WV1 (SP)(01) | |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -30 ~ 80 °C |
| Pixel Features : | Pixel Format | 480(RGB)×800 [WVGA] | Dot Pitch | 0.045×0.135 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.135×0.135 mm (H×V) [188PPI] | |
| Mechanical Size : | Display Area | 64.8×108 mm (H×V) | Bezel Area | 67.2×110.4 mm (H×V) |
| Outline Dim. | 71.4×120.4 mm (H×V) | Outline Depth | 2.5/4.31 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio | 3:5 (H:V) | Shape Style | ||
| Other Features : | Weight | 43.6/45.0g (Typ,/Max.) | Surface | Antiglare |
| Basic Information : | Brightness | 500 cd/m² (Typ.) | Contrast Ratio | 700:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 30 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.25/1.40 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 49% | sRGB | 69% coverage |
| Adobe RGB | 52% coverage | DCI-P3 | 51% coverage | |
| Rec.2020 | 37% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | Array | Lamp Type | WLED | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 5S2P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | 16.0V (Typ.) | Current Input | 40mA (Typ.) | ||
| Consumption | 640mW (Typ.) | |||||
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Signal Systerm : | Parallel RGB (1 ch, 8-bit) + SPI | Logic Voltage | -0.3≤VIL≤0.2VCC; 0.8VCC≤VIH≤VCC | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 2.9V (Typ.) | Current Input | 35/50mA (Typ./Max.) | ||
| Consumption | 102/145mW (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| Panasonic | AXT540124 | 0.4 mm | 40 pins | 1 pcs | ||
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 112 pcs / box | - | 478×365×162 mm |
