Product Details:
|
| MODEL NUMBER: | LA154WU1-SL01 | BRAND: | LG DISPLAY |
|---|---|---|---|
| SIZE: | 15.4 Inch | BRIGHTNESS: | 800CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1200 (WUXGA) 147PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| High Light: | 15.4" WLED Industrial LCD Display,800cd/m2 Industrial LCD Display,147PPI WUXGA Square Lcd Panel |
||
| Basic Info : | Panel Brand | Panel Model | LA154WU1-SL01 | |
|---|---|---|---|---|
| Diagonal Size | 15.4" | Application |
|
|
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LA154WU1 (SL)(01) | |
| Reliability : | Operating Temp. | -30 ~ 85 °C | Storage Temp. | -40 ~ 95 °C |
| Pixel Features : | Pixel Format | 1920(RGB)×1200 [WUXGA] | Dot Pitch | 0.0574×0.1722 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.1722×0.1722 mm (H×V) [147PPI] | |
| Mechanical Size : | Display Area | 330.624×206.64 mm (H×V) | Bezel Area | - |
| Outline Dim. | 341.2×219.14 mm (H×V) | Outline Depth | 6.95/13.0 (Typ./Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:10 (H:V) | Shape Style | ||
| Other Features : | Weight | 830/850g (Typ./Max.) | Surface | Glare (Haze 0%), Hard coating (3H) |
| Basic Information : | Brightness | 800 cd/m² (Typ.) | Contrast Ratio | 1450:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 10/8 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.25 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 88% | sRGB | 100% coverage |
| Adobe RGB | 85% coverage | DCI-P3 | 90% coverage | |
| Rec.2020 | 65% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance |
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 20K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | With LED Driver |
| Driver Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | - | ||
| Signal Systerm : | SLVS (1 ch, 2 port) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | 1.96±0.39A | ||
| Consumption | 23.52/28.22W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| 99S11D-40MA-D | 6 pins | 1 pcs | ||||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
