Product Details:
|
| MODEL NUMBER: | HSD050JDW2-B00 | BRAND: | HannStar |
|---|---|---|---|
| SIZE: | 5.0 Inch | BRIGHTNESS: | 1250 Cd/m² (Typ.) |
| Lamp Type: | LEDS | RESOLUTION: | 800(RGB)×480 [WVGA] 188PPI |
| VIEWING ANGLEG: | 20/20/20/20 (Min.)(CR≥100) | TEMPERATURE RANGE: | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
| Highlight: | 1250cd/M2 Industrial LCD Panel,188PPI Industrial LCD Panel,4.9W Lcd Video Panel |
||
| Basic Detail : | Manufacturer | Model Name | HSD050JDW2-B00 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | - | |
| Panel Size | 5.0 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | -40 ~ 85 °C | ST Temperature | -40 ~ 95 °C |
| Basic Information : | Luminance | 1250 cd/m² (Typ.) | Contrast Ratio | 800 : 1 (Min.) (Transmissive) |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | 22/8 (Max.)(Tr+Td) (ms) | |
| Viewing Angle | 20/20/20/20 (Min.)(CR≥100) | Operating Mode | HS-IPS, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.295; Wy:0.296 | Support Color | 16.7M (8-bit) |
| Color Temperature | 8247K | White Uniformity | 1.43 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 73% | sRGB | 94% coverage |
| Adobe RGB | 73% coverage | DCI-P3 | 76% coverage | |
| Rec.2020 | 55% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Pixel Features : | Number of Pixel | 800(RGB)×480 [WVGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.045×0.135 mm | Pixel Pitch(W×H) | 0.135×0.135 mm [188PPI] | |
| Physical Size : | Active Viewing | 108(W)×64.8(H) mm | Overall Dim. | 120.6(W)×80(H) mm |
| Bezel Opening | - | Overall Depth | 7.2/13.9 (Typ./Max.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 15:9 | Shape Style | ||
| Fixation : | Face mounting holes (4 pcs) on left, right, up slugs | |||
| Other Detail : | Mass | 105/110g (Typ./Max.) | Surface | Antiglare |
| Signal Electrical : | Input Current | 150mA (Typ.) | Input Voltage | 3.3V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | 0.5W (Max.) | Signal Interface | LVDS (1 ch, 8-bit) + SPI | |||
| Interface Features : | Position | - | Physical Type | FPC | ||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 0.5 mm | 50 pins | ||||
| Lamp Features: | Lamp Shape | Array | Lamp Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 6S3P | Life | 10K(Min.) (Hours) | |
| Lamp Electrical : | Input Current | 270mA (Max.) | Input Voltage | 20.4V (Max.) | ||
| Consumption | 4.9W (Max.) | |||||
| Interface Features : | Position | - | Physical Type | FPC | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| 1 pcs | 0.5 mm | |||||
| Backlight Driver : | No | |||||
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|---|---|---|
| 16 pcs / box | 456×350×187 mm |
