Product Details:
|
| MODEL NUMBER: | LD490EUE-FHB1 | BRAND: | LG DISPLAY |
|---|---|---|---|
| SIZE: | 49.0INCH | BRIGHTNESS: | 450CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1080 (FHD) 45PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
| High Light: | 45PPI WLED LCD Display,450cd/m2 WLED LCD Display,LD490EUE-FHB1 WLED Panel |
||
| Basic Information : | Brand | Model | LD490EUE-FHB1 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 49" | Alias | LD490EUE (FH)(B1) | |
| Environment : | Storage Temp. | -20 ~~ 65 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.18642×0.55926 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.55926×0.55926 (H×V) [45PPI] | |
| Mechanical Size : | Active Area(mm) | 1073.78(H) × 604(V) | Bezel Area(mm) | 1078.4(H) × 608.6(V) |
| Outline Dim.(mm) | 1096.2(H) × 632.5(V) | Depth(mm) | 17.0/29.6 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape / Portrait | |
| Other Spec : | Weight | 10.8/11.0Kgs (Typ./Max.) | Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 450 (Typ.) | Contrast Ratio | 1100:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Display Mode | S-IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 12 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.281; Y:0.288 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 9966K | White Uniformity | 1.54 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 70% | sRGB | 95% coverage |
| Adobe RGB | 72% coverage | DCI-P3 | 72% coverage | |
| Rec.2020 | 52% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.7V (Typ.) | Current Supply | 360/468mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 4.3/5.7W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 50K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 129.2/138.2/147.2V (Min./Typ./Max.) | Current Supply | 170mA (Typ.) | ||
| Consumption | 47W (Typ.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | SMH200-H07M | 1 pcs | 7 pins | 2.0 mm | BEL-7PINS-CNANCNA | |
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 22 pcs / box | - | 1300×1140×825 mm (L×W×H) |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
