Product Details:
|
| MODEL NUMBER: | LD320EUN-SEM1 | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
|---|---|---|---|
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | RESOLUTION: | 1920(RGB)×1080 (FHD) 69PPI |
| Lamp Type: | WLED | BRIGHTNESS: | 400CD/M2 |
| SIZE: | 32.0"inch | BRAND: | LG DISPLAY |
| Highlight: | LD320EUN-SEM1 Lcd Video Module,WVGA Industrial TFT Display,400cd/m2 Lcd Video Display |
||
| Basic Information : | Brand | Model | LD320EUN-SEM1 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 32.0" | Alias | LD320EUN (SE)(M1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.12125×0.36375 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.36375×0.36375 (H×V) [69PPI] | |
| Mechanical Size : | Active Area(mm) | 698.4(H) × 392.85(V) | Bezel Area(mm) | 705.6(H) × 400.1(V) |
| Outline Dim.(mm) | 727.4(H) × 429(V) | Depth(mm) | 16.2/29.7 (Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape / Portrait | |
| Other Spec : | Weight | 5.40/5.70Kgs (Typ./Max.) | Treatment | Antiglare (Haze 1%), Hard coating (2H) |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.12125×0.36375 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.36375×0.36375 (H×V) [69PPI] | |
| Mechanical Size : | Active Area(mm) | 698.4(H) × 392.85(V) | Bezel Area(mm) | 705.6(H) × 400.1(V) |
| Outline Dim.(mm) | 727.4(H) × 429(V) | Depth(mm) | 16.2/29.7 (Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape / Portrait | |
| Other Spec : | Weight | 5.40/5.70Kgs (Typ./Max.) | Treatment |
Antiglare (Haze 1%), Hard coating (2H)
|
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 492/640mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 5.9/7.7W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-R51S-HF | 1 pcs | 51 pins | 0.5 mm | LVDS-51P2C8B-048A | |
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 50K(Typ.) (Hours) | |
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | 20022WR-H14B2 | 1 pcs | 14 pins | 2.0 mm | ||
| Backlight Driver : | With LED Driver | |||||
| Driver Electrical : | Voltage Supply | 24.0±1.2V | Current Supply | 1.33/1.45A (Typ./Max.) | ||
| Consumption | 31.9/34.8W (Typ./Max.) | |||||
