Product Details:
|
| MODEL NUMBER: | LB050WQ3-TD02 | TEMPERATURE RANGE: | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
|---|---|---|---|
| VIEWING ANGLEG: | 65/65/50/60 (Typ.)(CR≥10 | RESOLUTION: | 480×272(RGB), WQVGA, 110PPI |
| Lamp Type: | WLED | BRIGHTNESS: | 500CD/M2 |
| SIZE: | 5.0 Inch | BRAND: | LG DISPLAY |
| Highlight: | LB050WQ3-TD02 Lcd Video Module,480×272 Industrial TFT Display,VGA Touch Lcd Video Display |
||
| Basic Info : | Panel Brand | Panel Model | LB050WQ3-TD02 | |
|---|---|---|---|---|
| Diagonal Size | 5.0" | Application |
|
|
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LB050WQ3 (TD)(02) | |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -30 ~ 80 °C |
| RoHS State | Vibration Rating | 1.5G (14.7 m/s²) |
| Pixel Features : | Pixel Format | 480×272(RGB) [WQVGA] | Dot Pitch | 0.2307×0.0765 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Horizontal Stripe | Pixel Pitch | 0.2307×0.2295 mm (H×V) [110PPI] | |
| Mechanical Size : | Display Area | 110.736×62.424 mm (H×V) | Bezel Area | 113.72×65.4 mm (H×V) |
| Outline Dim. | 124×77.2 mm (H×V) | Outline Depth | 3.35 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style | ||
| Other Features : | Weight | 70.0g (Typ.) | Surface | Antiglare |
| Basic Information : | Brightness | 500 cd/m² (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 65/65/50/60 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transmissive | |
| Viewing Direction | 6 o'clock | Response Time | 25 (Typ.)(Tr+Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.318; Wy:0.337 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6176K | White Uniformity | 1.42 (Max.)(5 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 46% | sRGB | 64% coverage |
| Adobe RGB | 48% coverage | DCI-P3 | 48% coverage | |
| Rec.2020 | 34% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | 2 strings | Lamp Type | WLED | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 6S2P | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | Current Input | 20mA (Typ.) | |||
| Consumption | 770mW (Typ.) | |||||
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Signal Systerm : | Parallel RGB (1 ch, 8-bit) | Logic Voltage | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 2.5/3.3V (Typ.)(VDD) | Current Input | - | ||
| Consumption | 155/182mW (Typ./Max.) | |||||
| Interface Features : | Type | FPC | Position | - | ||
| FPC Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| 0.5 mm | 45 pins | 1 pcs | ||||
