Product Details:
|
| MODEL NUMBER: | LA061WQ1-TD05 | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
|---|---|---|---|
| VIEWING ANGLEG: | 80/80/80/80 (Typ.)(CR≥10) | RESOLUTION: | 480(RGB)×272 (WQVGA) |
| Lamp Type: | WLED | Signal Interface: | LVDS |
| SIZE: | 6.1INCH | BRAND: | LG DISPLAY |
| Highlight: | LA061WQ1-TD05 TFT LCD Panel,WLED Lamp LCD Display Panels,TFT LCD Display SVGA 119PPI |
||
| Basic Information : | Manufacturer | Panel Model | Panel Type | Alias |
|---|---|---|---|---|
| LA061WQ1-TD05 | a-Si TFT-LCD , LCM | LA061WQ1 (TD)(05) | ||
| Environment : | RoHS State | Operating Temp. | Storage Temp. | Vibration Level |
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| - | - | - | |
| Best View on | Display Mode | Contrast Ratio | |
| - | TN, Normally White, Transmissive | - | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| - | 262K (6-bit) | - |
| Panel Size : | 6.1" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Format | Pixel Configuration | Pixel Pitch (mm) | Dot Pitch (mm) |
| 480(RGB)×272 [WQVGA] | RGB Vertical Stripe | - | - | |
| Outline Features : | Form Factor | Orientation | Aspect Ratio | Shape Style |
| Flat Rectangle | Landscape type | 16:9 (H:V) | ||
White, Transmissive LCM product, LA061WQ1-TD05 can provides . Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type. LA061WQ1-TD05 utilizes Parallel RGB (1 ch, 6-bit) as it's signal inputting systerm. For more latest product detail of LA061WQ1-TD05 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with LG Display or it's distributor. The above parameters are not from the datasheet, only as a reference, please use with caution!
