LP156WHB-TLB1 LG Display 15.6" 1366(RGB)×768 200 cd/m² INDUSTRIAL LCD DISPLAY

Large Image : LP156WHB-TLB1 LG Display 15.6" 1366(RGB)×768 200 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:

Place of Origin:	JAPAN
Brand Name:	LG DISPLAY
Certification:	ISO9001
Model Number:	LP156WHB-TLB1

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	STANDARD PACKING
Delivery Time:	1-2 DAYS
Payment Terms:	TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability:	800PCS

Contact Now

LP156WHB-TLB1 LG Display 15.6" 1366(RGB)×768 200 cd/m² INDUSTRIAL LCD DISPLAY

Description

MODEL NUMBER:	LP156WHB-TLB1	BRAND:	LG DISPLAY
SIZE:	15.6 Inch	BRIGHTNESS:	200CD/M2
Lamp Type:	WLED	RESOLUTION:	1366(RGB)×768, WXGA, 100PPI
VIEWING ANGLEG:	45/45/15/35 (Min.)(CR≥10)	TEMPERATURE RANGE:	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Highlight:	LP156WHB-TLB1 TFT LCD Panel , WLED Lamp LCD Display Panels , TFT LCD Display SVGA 119PPI

LG Display LP156WHB-TLB1 Application Details

Basic Information :	Brand LP156WHB-TLB1 26 CompatibleModel Type a-Si TFT-LCD , LCM Used For 15.6 inchScreen Size Alias LP156WHB (TL)(B1)
Environment :	Storage Temp. -20 ~ 60 °C Operating Temp. 0 ~ 50 °C

LG Display LP156WHB-TLB1 Mechanical Details

Pixel Features :	Resolution 1366(RGB)×768, WXGA Dot Pitch(mm) 0.084×0.252 (H×V) Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.252×0.252 (H×V) [100PPI]
Mechanical Size :	Active Area(mm) 344.232(H) × 193.536(V) Bezel Area(mm) 347.5(H) × 196.8(V) Outline Dim.(mm) 359.5(H) × 223.5(V) Depth(mm) 3.5/3.8 (Typ./Max.)
Outline Features :	Form Style Flat Rectangle Shape Style Flat (PCBA Flat, T3.4~4.0mm) Aspect Ratio 16:9 (H:V) Orientation Landscape type
Mounting :	Face mounting holes (8 pcs) on up, down slugs
Other Spec :	Weight 400g (Max.) Treatment Antiglare

LG Display LP156WHB-TLB1 Optical Details

Basic Information :	Luminance(cd/m²) 200 (Typ.) Contrast Ratio 350:1 (Typ.) (Transmissive) Viewing Angle 45/45/15/35 (Min.)(CR≥10) Display Mode TN, Normally White, Transmissive Best View on 6 o'clock Response(ms) 16 (Typ.)(Tr+Td)
Color Performance :	White Coordinate Wx:0.313; Wy:0.329 Display Colors 262K (6-bit) Color Temperature 6485K White Uniformity 1.40/1.60 (Typ./Max.)(13 points)
1931 Color Gamlt :	NTSC Ratio 47% sRGB 66% coverage Adobe RGB 49% coverage DCI-P3 49% coverage Rec.2020 35% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LP156WHB-TLB1 Interface Detail

Signal Electrical :	Voltage Supply 3.3V (Typ.) Current Supply 220/255mA (Typ./Max.) Consumption 0.7/0.8W (Typ./Max.)
Signal Type :	LVDS (1 ch, 6-bit) Logic Voltage -
Interface Features :	Position ConnectorType
Interface Detail :	Brand Model Pitch Pins Quantity Pin Configuration LS Mtron GT05Q-40S-H10 0.5 mm 40 pins 1 pcs LVDS-40P1C6B-060B

LG Display LP156WHB-TLB1 Backlight Details

Backlight Features :	Type WLED Quantity - Position Edge light type Replacement - Shape - Life Time 12K(Min.) (Hours)
Interface Features :	Position - Type Included in panel signal interface
Backlight Driver :	With LED Driver
Driver Electrical :	Voltage Supply 7.0/12.0/21.0V (Min./Typ./Max.) Current Supply 175/193mA (Typ./Max.) Consumption 2.1/2.3W (Typ./Max.)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.

LP156WHB-TLB1 LG Display 15.6" 1366(RGB)×768 200 cd/m² INDUSTRIAL LCD DISPLAY 1
