Product Details:
|
MODEL NUMBER: | LM270WQ8-SSA1 | BRAND: | LG DISPLAY |
---|---|---|---|
SIZE: | 27.0INCH | BRIGHTNESS: | 350CD/M2 |
Lamp Type: | WLED | RESOLUTION: | 2560(RGB)×1440 [Quad-HD] 107PPI |
VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
High Light: | LM270WQ8-SSA1 TFT LCD Panel,Symmetry TFT LCD Panel,LVDS TFT LCD Module |
Basic Information : | Brand | Model | LM270WQ8-SSA1 | |
---|---|---|---|---|
Type | LCM a-Si TFT-LCD | Used For | ||
Screen Size | 27.0" | Alias | LM270WQ8 (SS)(A1) | |
Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
Pixel Features : | Resolution | 2560(RGB)×1440, Quad-HD | Dot Pitch(mm) | 0.0777×0.2331 (H×V) |
---|---|---|---|---|
Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.2331×0.2331 (H×V) [107PPI] | |
Mechanical Size : | Active Area(mm) | 596.736(H) × 355.664(V) | Bezel Area(mm) | - |
Outline Dim.(mm) | 608.6(H) × 348.6(V) | Depth(mm) | 7.5/12.8 (Typ./Max.) | |
Outline Features : | Form Style | Flat Rectangle | Outline Shape | 3-side borderless |
Aspect Ratio | 15:9 (H:V) | Orientation | Landscape type | |
Mounting : | Rear mounting holes | |||
Other Spec : | Weight | 3.02/3.17Kgs (Typ./Max.) | Treatment | Antiglare (Haze 25%), Hard coating (3H) |
Basic Information : | Luminance(cd/m²) | 350 (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
---|---|---|---|---|
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
Best View on | Symmetry | Response(ms) | 14 (Typ.)(G to G) | |
Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 1.07B (8-bit + Hi-FRC) |
Color Temperature | 6485K | White Uniformity | 1.33 (Max.)(9 points) | |
1931 Color Gamlt : | NTSC Ratio | - | sRGB | 100% coverage |
Adobe RGB | 85% coverage | DCI-P3 | 91% coverage | |
Rec.2020 | 67% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
Signal Electrical : | Voltage Supply | 10.0V (Typ.) | Current Supply | 360/430mA (Typ./Max.) | ||
---|---|---|---|---|---|---|
Consumption | 3.6/4.3W (Typ./Max.) | |||||
Signal Type : | eDP (4 Lanes), HBR1 (2.7G/lane) | Signal Voltage | - | |||
Interface Features : | Position | - | Type | Connector | ||
Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
LS Mtron | GT05Q-30S-H10-MN | 1 pcs | 30 pins | 0.5 mm | EDP-30P4L-031A |
Backlight Features: | Shape | 4 strings | Type | WLED | Position | Edge light type (Bottom side) |
---|---|---|---|---|---|---|
Replacement | - | Quantity | 19S4P | Life Time | 30K(Min.) (Hours) | |
Lamp Electrical : | Voltage Supply | 53.5±3.8V | Current Supply | 62/67mA (Typ./Max.) | ||
Consumption | 13.3/14.3W (Typ./Max.) | |||||
Interface Features : | Position | Type | Connector | |||
Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
JST | BM06B-SHJS-TB(HF) | 1 pcs | 6 pins | 1.0 mm | BLE-6PINS-CCAACC | |
Backlight Driver : | No |
Package Box : | Quantity | Weight | Box Size |
---|---|---|---|
10 pcs / box | - | 710×365×448 mm (L×W×H) |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
