Product Details:
|
| MODEL NUMBER: | LM225WU1-SSA1 | BRAND: | LG DISPLAY |
|---|---|---|---|
| SIZE: | 22.5 Inch | BRIGHTNESS: | 250CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1200, WUXGA, 100PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | 22.5in WLED TFT Panel,100PPI WLED TFT Panel,LM225WU1-SSA1 Square Tft Panel |
||
| Basic Information : | Brand | Model | LM225WU1-SSA1 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 22.5" | Alias | LM225WU1 (SS)(A1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1200, WUXGA | Dot Pitch(mm) | 0.08475×0.24765 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.25425×0.24765 (H×V) [100PPI] | |
| Mechanical Size : | Active Area(mm) | 488.16(H) × 297.18(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 496.2(H) × 313.9(V) | Depth(mm) | 8.35/12.1 (Typ./Max>) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | 3-side borderless |
| Aspect Ratio | - | Orientation | Landscape type | |
| Mounting : | Rear mounting holes (9-M3) | |||
| Other Spec : | Weight | 1.76Kgs (Typ.) | Treatment | Antiglare, Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 250 (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 14 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 16.7M (6-bit + Hi-FRC) |
| Color Temperature | 6485K | White Uniformity | 1.33 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 72% | sRGB | 95% coverage |
| Adobe RGB | 74% coverage | DCI-P3 | 75% coverage | |
| Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 5.0V (Typ.) | Current Supply | 0.5/0.63A (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 2.5/3.13W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| UJU | IS100-L30O-C23 | 1 pcs | 30 pins | 1.0 mm | LVDS-30P2C8B-160B | |
| Backlight Features: | Shape | 3 strings | Type | WLED | Position | Edge light type (Bottom side) |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 3 strings | Life Time | 30K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 53±3.8V | Current Supply | 55/60mA (Typ./Max.) | ||
| Consumption | 8.8/9.4W (Typ./Max.) | |||||
| Interface Features : | Position | Type | Connector | |||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | 10035WR-H06D | 1 pcs | 6 pins | 1.0 mm | BLE-6PINS-CCAANC | |
| Backlight Driver : | No | |||||
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | No |
| Power Consumption : | 11.3W (Typ.) |
