Product Details:
|
| MODEL NUMBER: | LP097QX1-SPA1 | BRAND: | LG DISPLAY |
|---|---|---|---|
| SIZE: | 9.7INCH | BRIGHTNESS: | 440CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 2048(RGB)×1536, QXGA, 264PPI |
| VIEWING ANGLEG: | 80/80/80/80 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Signal Interface: | LVDS | ||
| Highlight: | WLED TTL Industrial Lcd Display,WLED LVDS Lcd Video Panel,Hard Coating Industrial TFT Display |
||
| Basic Info : | Panel Brand | Panel Model | LP097QX1-SPA1 | |
|---|---|---|---|---|
| Diagonal Size | 9.7" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LP097QX1 (SP)(A1) | |
| Reliability : | Operating Temp. | 0 ~ 50 °C | Storage Temp. | -20 ~ 60 °C |
| Pixel Features : | Pixel Format | 2048(RGB)×1536 [QXGA] | Dot Pitch | 0.032×0.096 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.096×0.096 mm (H×V) [264PPI] | |
| Mechanical Size : | Display Area | 196.608×147.456 mm (H×V) | Bezel Area | - |
| Outline Dim. | 208.88×167.12 mm (H×V) | Outline Depth | 2.68/5.17 (Max.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Other Features : | Weight | 134g (Max.) | Surface | Glare (Haze 0%), Hard coating (3H), Antireflection |
| Basic Information : | Brightness | 440 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 16 (Typ.)(G to G) (ms) | |
| Color Performance : | Chromaticity | Wx:0.306; Wy:0.320 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6976K | White Uniformity | 1.25/1.43 (Typ./Max.)(160 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 72% | sRGB | 96% coverage |
| Adobe RGB | 73% coverage | DCI-P3 | 74% coverage | |
| Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | 12 strings | Lamp Type | WLED | Life Time | 10K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Lamp Electrical : | Voltage Input | Current Input | 5/18.5/25mA (Min./Typ./Max.) | |||
| Consumption | 4.4W (Typ.) | |||||
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Signal Systerm : | eDP (4 Lanes) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 320±48mA | ||
| Consumption | 1.06/1.19W (Typ./Max.) | |||||
| Interface Features : | Type | FPC | Position | - | ||
| FPC Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| 51 pins | 1 pcs | |||||
| Frame Frequency : | 60Hz |
|---|---|
| Reverse Scan : | No |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
whose pixels are arranged in RGB Vertical Stripe, according to calculation of Panelook it's pixel density is 264 PPI. As for mechanical detail, it features active area of 196.608(W)×147.456(H) mm, outline size of 208.88(W)×167.12(H)×5.17(D) mm, with surface treament of Glare (Haze 0%), Hard coating (3H), Antireflection, net weight of 134g (Max.). As a IPS, Normally Black, Transmissive LCM product, LP097QX1-SPA1 can provides 440 cd/m² display brightness 800:1 transimissive contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 16 (Typ.)(G to G) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 72% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 10K hours, external backlight driver is additionally needed. LP097QX1-SPA1 utilizes eDP (4 Lanes) as it's signal inputting systerm, which connected by 51 pins FPC with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of LP097QX1-SPA1 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with LG Display or it's distributor. All specification details are inputted by Panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
