Product Details:
|
| MODEL NUMBER: | LC430EUE-FHM3 | BRAND: | LG DISPLAY |
|---|---|---|---|
| SIZE: | 43 Inch | BRIGHTNESS: | 300CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1080 (FHD) 51PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | 43in Square Tft Display,51PPI Square Tft Display,300cd/M2 Tft Lcd Screen |
||
| Basic Information : | Brand | Model | LC430EUE-FHM3 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 43" | Alias | LC430EUE (FH)(M3) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.1634×0.4902 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.4902×0.4902 (H×V) [51PPI] | |
| Mechanical Size : | Active Area(mm) | 941.184(H) × 529.416(V) | Bezel Area(mm) | 945.8(H) × 533.87(V) |
| Outline Dim.(mm) | 973(H) × 565.8(V) | Depth(mm) | 28.6 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 7.00/7.35Kgs (Typ./Max.) | Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Signal Electrical : | Voltage Supply | 12.7V (Typ.) | Current Supply | 350/450mA (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | 4.4/5.8W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | Type | Connector | |||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RXE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Direct light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 30K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 120.5/140.0V (Typ./Max.) | Current Supply | 180mA (Typ.) | ||
| Consumption | 43.4/50.4W (Typ./Max.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | SMH200-H07M | 1 pcs | 7 pins | 2.0 mm | BLE-7PINS-CNANCNA | |
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 26 pcs / box | - | 1300×1140×746 mm (L×W×H) |
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
