LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY

LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY
LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: LG DISPLAY
Certification: ISO9001
Model Number: LC550EGG-FHM1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 300PCS
Contact Now

LC550EGG-FHM1 LG Display 55" 3840(RGB)×2160 390 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: LC550EGG-FHM1 BRAND: LG DISPLAY
SIZE: 55 Inch BRIGHTNESS: 390CD/M2
Lamp Type: WLED RESOLUTION: 3840(3)×2160, UHD, 80PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Highlight:

WVGA Industrial TFT Display

,

RGB Vertical LCD Display

,

Capacitive TFT Touch Panel

LG Display LC550EGG-FHM1 Application Details

Basic Detail :
Manufacturer

LC550EGG-FHM1Model Name
Panel Type
a-Si TFT-LCD , LCM
Another Name
LC550EGG (FH)(M1)
Panel Size
55 inch
Designed For
Maximum Ratings :
OP Temperature
0 ~ 50 °C
ST Temperature
-20 ~ 60 °C



LG Display LC550EGG-FHM1 Optical Details

Basic Detail :
Luminance
390 cd/m² (Typ.)
Contrast Ratio
1100:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
9 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Operating Mode
IPS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.281; Wy:0.288
Support Color
1.07B (8-bit + Dithering)
Color Temperature
9966K
White Variation
1.54 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
69%
sRGB
94% coverage
Adobe RGB
71% coverage
DCI-P3
71% coverage
Rec.2020
51% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LC550EGG-FHM1 Mechanical Details

Pixel Features :
Number of Pixel
3840(3)×2160, UHD
Arrangement
RGBW Vertical Stripe
Dot Pitch(W×H)
0.105×0.315 mm
Pixel Pitch(W×H)
0.315×0.315 mm [80PPI]
Physical Size :
Active Viewing
1209.6(W)×680.4(H) mm
Overall Dim.
1233.4(W)×706.8(H) mm
Bezel Opening
1214.6(W)×685.4(H) mm
Overall Depth
22.6 (Typ.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9
Shape Style

Other Detail :
Mass
12.5/13.0Kgs (Typ./Max.)
Surface
Antiglare (Haze 1%), Hard coating (3H)





LG Display LC550EGG-FHM1 Interface Detail

Signal Electrical :
Input Current
1.17/1.52A (Typ./Max.)
Input Voltage
12.0V (Typ.)(VLCD)
Consumption
14.83/19.28W (Typ./Max.)
Signal Interface
EPI
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
HRS
TF06L-60S-0.5SH
0.5 mm
60 pins
2 pcs



LG Display LC550EGG-FHM1 Lightting Details

Lamp Features :
Lamp Type
WLED
Amount
-
Position
Edge light type
Exchange
-
Lamp Shape
-
Lamp Life
30K(Min.) (Hours)
Lamp Electrical :
Input Voltage
185.4±15V
Input Current
180mA (Typ.)
Consumption
66.7/72.1W (Typ./Max.)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
YEONHO
SMH200-H07M
2.0 mm
7 pins
1 pcs
BLE-7PINS-CNANCNA
Backlight Driver :
No



LG Display LC550EGG-FHM1 Packing Details

Package Box : Amount Size (L×W×H) Weight
22 pcs / box - 1440×1140×950 mm



 Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
