LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY

LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY
LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: LG DISPLAY
Certification: ISO9001
Model Number: LM375QW2-SSA1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 200PCS
Contact Now

LM375QW2-SSA1 LG Display 37.5" 3840(RGB)×1600 450 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: LM375QW2-SSA1 BRAND: LG DISPLAY
SIZE: 37.5"inch BRIGHTNESS: 450CD/M2
Lamp Type: WLED RESOLUTION: 3840(RGB)×1600 [UHD] 110PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
High Light:

WVGA TFT LCD Panel

,

Antiglare NEC TFT Display

,

Symmetry TFT LCD Panel

LG Display LM375QW2-SSA1 Application Details

Basic Information :
Brand

LM375QW2-SSA1Model
Type
a-Si TFT-LCD , LCM
Used For



Screen Size
37.5 inch
Alias
LM375QW2 (SS)(A1)
Environment :
Storage Temp.
-20 ~ 60 °C
Operating Temp.
0 ~ 50 °C



LG Display LM375QW2-SSA1 Mechanical Details

Pixel Features :
Resolution
3840(RGB)×1600, UHD
Dot Pitch(mm)
0.076×0.229 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.229×0.229 (H×V) [110PPI]
Mechanical Size :
Active Area(mm)
879.36(H) × 366.4(V)
Bezel Area(mm)
-
Outline Dim.(mm)
890.4(H) × 388.4(V)
Depth(mm)
13.45/18.69 (Typ./Max.)
Outline Features :
Form Style
Curved Display, R2300
Shape Style
3-side borderless
Aspect Ratio
24:10 (H:V)
Orientation
Landscape type
Mounting :
Rear mounting holes
Other Spec :
Weight
3.86/4.05Kgs (Typ./Max.)
Treatment
Antiglare (Haze 25%), Hard coating (3H)



LG Display LM375QW2-SSA1 Optical Details

Basic Information :
Luminance(cd/m²)
450 (Typ.), HDR600
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
14 (Typ.)(G to G)
Color Performance :
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
1.07B (8-bit + Hi-FRC)
Color Temperature
6485K
White Uniformity
1.33 (Max.)(9 points)



LG Display LM375QW2-SSA1 Interface Detail

Signal Electrical :
Voltage Supply
10.0V (Typ.)
Current Supply
850/1062mA (Typ./Max.)
Consumption
8.5/10.62W (Typ./Max.)
Signal Type :
eDP (2 ch, 4 Lanes), HBR2 (5.4G/lane)
Logic Voltage
-
Interface Features :
Position

ConnectorType
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
I-PEX
20525-060E-01
0.4 mm
60 pins
1 pcs




LG Display LM375QW2-SSA1 Backlight Details

Backlight Features :
Type
WLED
Quantity
-
Position
Edge light type
Replacement
-
Shape
-
Life Time
30K(Min.) (Hours)
Lamp Electrical :
Voltage Supply
43.2±3V
Current Supply
95/100mA (Typ./Max.)
Consumption
49.3/52.7W (Typ./Max.)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
YEONHO
SMH200-H12S4
2.0 mm
12 pins
2 pcs
BLE-12PINS-CNAACCCCAANC
Backlight Driver :
No



LG Display LM375QW2-SSA1 Packing Details

Package Box : Quantity Weight Box Size
10 pcs / box - 1084×622×483 mm (L×W×H)



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
