Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4

Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4
Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4 Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4 Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4 Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4 Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4

Large Image :  Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4

Product Details:
Place of Origin: JAPAN
Brand Name: LG. LCD
Certification: ISO9001
Model Number: LM240WU2-SLB4
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 200PCS
Contact Now

Hard Coating 94PPI TFT LCD Panel 24.0" 400cd/M2 LM240WU2-SLB4

Description
MODEL NUMBER: LM240WU2-SLB4 BRAND: LG. LCD
SIZE: 24.0INCH BRIGHTNESS: 400CD/M2
Lamp Type: WLED RESOLUTION: 1920(RGB)×1200 [WUXGA] 94PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
Highlight:

Hard Coating TFT LCD Panel

,

94PPI TFT LCD Panel

,

400cd/M2 Tft Lcd Screen

LG. LCD LM240WU2-SLB4 Application Details

Basic Info :
Panel Brand

LM240WU2-SLB4Panel Model
Diagonal Size
24.0"
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
LM240WU2 (SL)(B4)
Reliability :
Operating Temp.
0 ~ 50 °C
Storage Temp.
-20 ~ 60 °C



LG. LCD LM240WU2-SLB4 Mechanical Details

Pixel Features :
Pixel Format
1920(RGB)×1200, WUXGA
Dot Pitch
0.090×0.270 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.270×0.270 mm (H×V) [94PPI]
Mechanical Size :
Display Area
518.4×324 mm (H×V)
Bezel Area
523.4×329.0 mm (H×V)
Outline Dim.
546.4×350 mm (H×V)
Outline Depth
28.9 (Typ.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:10 (H:V)
Shape Style
Normal bezel
Holes & Brackets :
Side mounting holes
Other Features :
Weight
2.65/2.80Kgs (Typ./Max.)
Surface
Glare (Haze 0%), Hard coating (2H)



LG. LCD LM240WU2-SLB4 Optical Details

Basic Information :
Brightness
400 cd/m² (Typ.)
Contrast Ratio
800:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Optical Mode
S-IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
5.5/6.5 (Typ.)(Tr/Td) ms
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
16.7M (8-bit)
Color Temperature
6485K
Uniformity
1.43 (Max.)(13 points)
1931 Color Gamlt :
NTSC Ratio
73%
sRGB
95% coverage
Adobe RGB
76% coverage
DCI-P3
76% coverage
Rec.2020
54% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG. LCD LM240WU2-SLB4 Backlight Details

Back-light Features :
Lamp Type
CCFL
Amount
14 pcs
Life Time
50K(Min.) (Hours)
Replacement
-
Lamp Shape
Straight
Position
Direct light type
Lamp Electrical :
Voltage Input
950±200V
Current Input
3.7/4.2/4.7mA (Min./Typ./Max.)
Frequency
40/44/48KHz (Min./Typ./Max.)
Kick-off Voltage
-
Interface Features :
Type
Connector
Position
-
Lamp Driver
With Inverter
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
CNPLUS
1008-61114
2.0 mm
14 pins
1 pcs

Driver Electrical :
Voltage Input
24.0±2.4V
Current Input
2.75/3.02A (Typ./Max.)
Consumption
66.0/72.6W (Typ./Max.)



LG. LCD LM240WU2-SLB4 Interface Detail

Signal Systerm :
LVDS (2 ch, 8-bit)
Logic Voltage
-
Signal Electrical :
Voltage Input
12.0V (Typ.)
Current Input
410/472mA (Typ./Max.)
Consumption
4.92/6.30W (Typ./Max.)
Interface Features :
Type
Connector
Position
-
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
UJU
IS100-L30B-C23
1.0 mm
30 pins
1 pcs
LVDS-30P2C8B-160P



LG. LCD LM240WU2-SLB4 Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
6 pcs / box - 436×346×613 mm



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
