Product Details:
|
| MODEL NUMBER: | LC320DUE-FGA4 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 32.0inch | BRIGHTNESS: | 300CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1080 (FHD) 69PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | 32.0 Inch Square Tft Display,Square Tft Display 1920x1080,300cd/M2 Capacitive LCD Panel |
||
| Basic Information : | Brand | Model | LC320DUE-FGA4 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 32.0" | Alias | LC320DUE (FG)(A4) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.12125×0.36375 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.36375×0.36375 (H×V) [69PPI] | |
| Mechanical Size : | Active Area(mm) | 698.4(H) × 392.85(V) | Bezel Area(mm) | 700.6(H) × 396.5(V) |
| Outline Dim.(mm) | 730.94(H) × 429.84(V) | Depth(mm) | 26.0/42.0 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 3.70/3.90Kgs (Typ./Max.) | Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 300 (Typ.) | Contrast Ratio | 1200:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 7 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.281; Y:0.288 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 9966K | White Uniformity | 1.54 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 66% | sRGB | 93% coverage |
| Adobe RGB | 69% coverage | DCI-P3 | 69% coverage | |
| Rec.2020 | 49% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 500/650mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 6.0/8.26W (Typ./Max.) | |||||
| Signal Type : | LVDS (2 ch, 8-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Direct light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 30K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 111.6/118.8/127.8V (Min./Typ./Max.) | Current Supply | 250mA (Typ.) | ||
| Consumption | 29.7W (Typ.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| CNPLUS | 1504-12102 | 1 pcs | 2 pins | 5.0 mm | BLE-2PINS-CA | |
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 32 pcs / box | - | 1140×870×1149 mm (L×W×H) |
