LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI

LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI
LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI

Large Image :  LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI

Product Details:
Place of Origin: JAPAN
Brand Name: LG Display
Certification: ISO9001
Model Number: LC550EGH-FKM1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 160PCS

LC550EGH-FKM1 LG Display 55 Inch 3840×2160 670 Cd/M² INDUSTRIAL LCD DISPLAY 80PPI

Description
MODEL NUMBER: LC550EGH-FKM1 BRAND: LG Display
SIZE: 55 Inch BRIGHTNESS: 670CD/M2
Lamp Type: WLED RESOLUTION: 3840(3)×2160 (UHD) 80PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
High Light:

3840×2160 Lcd Display Panels

,

QVGA Square Tft Display

,

80PPI NEC TFT Display

LG Display LC550EGH-FKM1 Application Details

Basic Info :
Panel Brand

LC550EGH-FKM1Panel Model
Diagonal Size
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
LC550EGH (FK)(M1)
Reliability :
Operating Temp.
0 ~ 50 °C
Storage Temp.
-20 ~ 60 °C



LG Display LC550EGH-FKM1 Mechanical Details

Pixel Features :
Pixel Format
3840(3)×2160, UHD
Dot Pitch
-
Configuration
RGBW Vertical Stripe
Pixel Pitch
0.315×0.315 mm (H×V) [80PPI]
Mechanical Size :
Display Area
1209.6×680.4 mm (H×V)
Bezel Area
1215.6×685.9 mm (H×V)
Outline Dim.
1231.4×710 mm (H×V)
Outline Depth
24.77 (Typ.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style

Other Features :
Weight
11.3/12.0Kgs (Typ./Max.)
Surface
Antiglare (Haze 3%), Hard coating (2H)



LG Display LC550EGH-FKM1 Optical Details

Basic Information :
Brightness
670 cd/m² (Typ.)
Contrast Ratio
1400:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Optical Mode
IPS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
5 (Typ.)(G to G); 8 (Typ.)(MPRT) ms
Color Performance :
Chromaticity
Wx:0.281; Wy:0.288
Color Numbers
1.07B (8-bit + Dithering)
Color Temperature
9966K
Uniformity
1.54 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
82%
sRGB
100% coverage
Adobe RGB
80% coverage
DCI-P3
84% coverage
Rec.2020
61% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LC550EGH-FKM1 Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
-
Life Time
30K(Min.) (Hours)
Replacement
-
Lamp Shape
-
Position
Edge light type
Lamp Electrical :
Voltage Input
110.2/118.5/128.7V (Min./Typ./Max.)
Current Input
105mA (Typ.)
Consumption
74.7/81.1W (Typ./Max.)
Interface Features :
Type
Connector
Position
-
Lamp Driver
No
Interface Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
UJU
1.0 mm
8 pins
1 pcs
BLE-8PINS-CCCNNNNA
UJU
1.0 mm
8 pins
1 pcs
BLE-8PINGS-ANNNNCCC



LG Display LC550EGH-FKM1 Interface Detail

Signal Systerm :
EPI
Logic Voltage
-
Signal Electrical :
Voltage Input
12.0V (Typ.)
Current Input
970/1261mA (Typ./Max.)
Consumption
12.3/16W (Typ./Max.)
Interface Features :
Type
Connector
Position
-
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
HRS
0.5 mm
60 pins
2 pcs




LG Display LC550EGH-FKM1 Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
18 pcs / box - 1440×1140×960 mm



  FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
