LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI

LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI
LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI

Large Image :  LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI

Product Details:
Place of Origin: JAPAN
Brand Name: LG Display
Certification: ISO9001
Model Number: LC550EUE-FKM1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 160PCS
Contact Now

LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI

Description
MODEL NUMBER: LC550EUE-FKM1 BRAND: LG Display
SIZE: 55 Inch BRIGHTNESS: 400CD/M2
Lamp Type: WLED RESOLUTION: 1920(RGB)×1080 (FHD) 40PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
High Light:

40PPI NEC TFT Display

,

Capacitive TFT Touch Panel

,

VGA Lcd Display Panels

LG Display LC550EUE-FKM1 Application Details

Basic Detail :
Manufacturer

LC550EUE-FKM1Model Name
Panel Type
a-Si TFT-LCD , LCM
Another Name
LC550EUE (SE)(M1)
Panel Size
55 inch
Designed For
Maximum Ratings :
OP Temperature
0 ~ 50 °C
ST Temperature
-20 ~ 60 °C



LG Display LC550EUE-FKM1 Optical Details

Basic Detail :
Luminance
400 cd/m² (Typ.)
Contrast Ratio
1200:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
6 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Operating Mode
S-IPS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.281; Wy:0.288
Support Color
16.7M (8-bit)
Color Temperature
9966K
White Variation
1.35 (Max.)(5 points)
1931 Color Gamlt :
NTSC Ratio
71%
sRGB
97% coverage
Adobe RGB
73% coverage
DCI-P3
73% coverage
Rec.2020
53% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LC550EUE-FKM1 Mechanical Details

Pixel Features :
Number of Pixel
1920(RGB)×1080, FHD
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.210×0.630 mm
Pixel Pitch(W×H)
0.630×0.630 mm [40PPI]
Physical Size :
Active Viewing
1209.6(W)×680.4(H) mm
Overall Dim.
1240.8(W)×714.7(H) mm
Bezel Opening
1214.6(W)×685.4(H) mm
Overall Depth
14.0 (Typ.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9
Shape Style

Fixation :
Rear mounting holes
Other Detail :
Mass
11.7/12.3Kgs (Typ./Max.)
Surface
Antiglare (Haze 3%), Hard coating (2H)



LG Display LC550EUE-FKM1 Interface Detail

Signal Electrical :
Input Current
300/390mA (Typ./Max.)
Input Voltage
12.7V (Typ.)
Consumption
3.8/5.0W (Typ./Max.)
Signal Interface
LVDS (2 ch, 8-bit)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
JAE
FI-RE51S-HF
0.5 mm
51 pins
1 pcs




LG Display LC550EUE-FKM1 Lightting Details

Lamp Features :
Lamp Type
WLED
Amount
-
Position
Edge light type
Exchange
-
Lamp Shape
-
Lamp Life
30K(Min.) (Hours)
Lamp Electrical :
Input Voltage
186±18V
Input Current
180mA (Typ.)
Consumption
67/73.4W (Typ./Max.)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
YEONHO
SMH200-H07M
2.0 mm
7 pins
1 pcs
BLE-7PINS-CNANCNA
Backlight Driver :
No



LG Display LC550EUE-FKM1 Packing Details

Package Box : Amount Size (L×W×H) Weight
20 pcs / box - 1440×1140×980 mm






FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.



LC550EUE-FKM1 LG Display 55" 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY 40PPI 0
