Product Details:
|
| MODEL NUMBER: | LD650EUF-FHB1 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 65 Inch | BRIGHTNESS: | 450CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1080, FHD, 34PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | NTSC Lcd Video Panel,34PPI Industrial Lcd Display,VGA Lcd Display Panels |
||
| Basic Information : | Brand | Model | LD650EUF-FHB1 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 65" | Alias | LD650EUF (FH)(B1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 1920(RGB)×1080, FHD | Dot Pitch(mm) | 0.248×0.744 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.744×0.744 (H×V) [34PPI] | |
| Mechanical Size : | Active Area(mm) | 1428.48(H) × 803.52(V) | Bezel Area(mm) | 1433.1(H) × 808.1(V) |
| Outline Dim.(mm) | 1450.9(H) × 832(V) | Depth(mm) | 16.5 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape / Portrait | |
| Other Spec : | Weight | 22.3/23.0Kgs (Typ./Max.) | Treatment | Antiglare (Haze 1%), Hard coating (3H) |
| Basic Information : | Luminance(cd/m²) | 450 (Typ.) | Contrast Ratio | 1300:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Display Mode | S-IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 10 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.281; Y:0.288 | Display Colors | 16.7M/1.06B (8-bit / 8-bit + Dithering) |
| Color Temperature | 9966K | White Uniformity | 1.54 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 70% | sRGB | 96% coverage |
| Adobe RGB | 72% coverage | DCI-P3 | 72% coverage | |
| Rec.2020 | 52% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 12.0V (Typ.) | Current Supply | 309/402mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 3.71/4.83W (Typ./Max,) | |||||
| Signal Type : | LVDS (4 ch, 8/10-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JAE | FI-RXE51S-HF | 1 pcs | 51 pins | 0.5 mm | ||
| JAE | FI-RXE41S-HF | 1 pcs | 41 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 50K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 220.32/222.5/224.08V (Min./Typ./Max.) | Current Supply | 180mA (Typ.) | ||
| Consumption | 80.1/87.9W (Typ./Max.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | SMH200-H07M | 1 pcs | 7 pins | 2.0 mm | ||
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 18 pcs / box | - | 1700×1140×1090 mm (L×W×H) |
