LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI

LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI
LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI

Large Image :  LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI

Product Details:
Place of Origin: JAPAN
Brand Name: LG Display
Certification: ISO9001
Model Number: LM315QU1-SSA1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 120PCS
Contact Now

LM315QU1-SSA1 LG Display 32.0" 7680×4320 400cd/m2 INDUSTRIAL LCD DISPLAY 279PPI

Description
MODEL NUMBER: LM315QU1-SSA1 BRAND: LG Display
SIZE: 32.0INCH BRIGHTNESS: 400CD/M2
Lamp Type: WLED RESOLUTION: 7680(RGB)×4320 [QUHD] 279PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Highlight:

400cd/m2 NTSC Lcd Video Panel

,

279PPI TFT Touch Panel

,

680×4320 VGA Lcd Display Panels

LG Display LM315QU1-SSA1 Application Details

Basic Detail :
Manufacturer

LM315QU1-SSA1Model Name
Panel Type
a-Si TFT-LCD , LCM
Another Name
LM315QU1 (SS)(A1)
Panel Size
32.0 inch
Designed For
Maximum Ratings :
OP Temperature
0 ~ 50 °C
ST Temperature
-20 ~ 60 °C



LG Display LM315QU1-SSA1 Optical Details

Basic Detail :
Luminance
400 cd/m² (Typ.)
Contrast Ratio
1300:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
14 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
IPS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Support Color
1.07B (10-bit)
Color Temperature
6485K
White Variation
1.33 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
109%
sRGB
100% coverage
Adobe RGB
100% coverage
DCI-P3
99% coverage
Rec.2020
81% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LM315QU1-SSA1 Mechanical Details

Pixel Features :
Number of Pixel
7680(RGB)×4320, QUHD
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.0303×0.0909 mm
Pixel Pitch(W×H)
0.0909×0.0909 mm [279PPI]
Physical Size :
Active Viewing
698.11(W)×392.69(H) mm
Overall Dim.
717.8(W)×412.5(H) mm
Bezel Opening
-
Overall Depth
10.8/17.1 (Typ./Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
16:9
Shape Style
4-side borderless
Fixation :
Rear mounting holes
Other Detail :
Mass
3.71/3.90Kgs (Typ./Max.)
Surface




LG Display LM315QU1-SSA1 Interface Detail

Signal Electrical :
Input Current
1.9/2.37A (Typ./Max.)
Input Voltage
10.0V (Typ.)
Consumption
19/23.7W (Typ./Max.)
Signal Interface
V-by-One 16 lane × 2ch
Interface Features :
Position

ConnectorType
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
UJU
IS050-C51B-C39-A
0.5 mm
51 pins
2 pcs

UJU
IS050-C41B-C39-A
0.5 mm
41 pins
1 pcs



LG Display LM315QU1-SSA1 Lightting Details

Lamp Features :
Lamp Type
WLED
Amount
19S4P
Position
Edge light type
Exchange
-
Lamp Shape
4 strings
Lamp Life
30K(Min.) (Hours)
Lamp Electrical :
Input Voltage
57±3.8V
Input Current
130/135mA (Typ./Max.)
Consumption
59.3/63.2W (Typ./Max.)
Interface Features :
Position

ConnectorType
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
YEONHO
20037WR-H12
2.0 mm
12 pins
1 pcs
BLE-12PINS-CCAACCCCAACC
Backlight Driver :
No



LG Display LM315QU1-SSA1 Packing Details

Package Box : Amount Size (L×W×H) Weight
14 pcs / box -



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
