Product Details:
|
| MODEL NUMBER: | LC430DGE-FJM2 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 43 Inch | BRIGHTNESS: | 390CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 3840(3)×2160, UHD, 103PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | 3840×2160 NTSC Lcd Video Panel,103PPI TFT Touch Panel,390cd/m2 VGA Lcd Display Panels |
||
| Basic Info : | Panel Brand | Panel Model | LC430DGE-FJM2 | |
|---|---|---|---|---|
| Diagonal Size | 43" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | LC430DGE (FJ)(M2) | |
| Reliability : | Operating Temp. | 0 ~ 50 °C | Storage Temp. | -20 ~ 60 °C |
| Pixel Features : | Pixel Format | 3840(3)×2160 [UHD] | Dot Pitch | 0.0817×0.2451 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGBW Vertical Stripe | Pixel Pitch | 0.2451×0.2451 mm (H×V) [103PPI] | |
| Mechanical Size : | Display Area | 941.184×529.416 mm (H×V) | Bezel Area | 945.2×533.4 mm (H×V) |
| Outline Dim. | 975.5×582.3 mm (H×V) | Outline Depth | 41.0 (Typ.) mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 16:9 (H:V) | Shape Style | ||
| Other Features : | Weight | 5.70/6.30Kgs (Typ./Max.) | Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Basic Information : | Brightness | 390 cd/m² (Typ.) | Contrast Ratio | 1100:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Optical Mode | IPS, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 6 (Typ.)(G to G) (ms) | |
| Color Performance : | Chromaticity | Wx:0.281; Wy:0.288 | Color Numbers | 1.07B (8-bit + Dithering) |
| Color Temperature | 9966K | White Uniformity | 1.54 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 70% | sRGB | 98% coverage |
| Adobe RGB | 72% coverage | DCI-P3 | 73% coverage | |
| Rec.2020 | 52% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 30K(Min.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Direct light type | |
| Lamp Electrical : | Voltage Input | 26.1/52.2V (Typ.)(VF1/VF2) | Current Input | 600/600mA (Typ.)(IF1/IF2) | ||
| Consumption | 47.0/52.7W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| Signal Systerm : | V-by-One 8 lane | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.7V (Typ.) | Current Input | 0.93/1.2A (Typ./Max.) | ||
| Consumption | 11.1/14.4W (Typ./Max.) | |||||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FI-RXE51S-HF | 0.5 mm | 51 pins | 1 pcs | ||
| Package Carton : | Amount | Net Weight | Carton Size (L×W×H) |
|---|---|---|---|
| 16 pcs / box | - | 1300×1140×757 mm |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
