Product Details:
|
| MODEL NUMBER: | LP140WF6-SPB6 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 14.0 Inch | BRIGHTNESS: | 300CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1080 (FHD) 157PPI |
| VIEWING ANGLEG: | 80/80/80/80 (Min.)(CR≥10 | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | 157PPI Lcd Video Display,14.0" Lcd Video Display,Square Tft Panel 300CD/M2 |
||
| Basic Info : | |
|---|---|
| Reliability : |
| Pixel Features : | |
|---|---|
| Mechanical Size : | |
| Outline Features : | |
| Holes & Brackets : |
| Basic Information : | |
|---|---|
| Color Performance : |
| Frame Frequency : | |
|---|---|
| Reverse Scan : |
| Back-light Features : | |
|---|---|
| Interface Features : |
| Signal Systerm : | |
|---|---|
| Interface Features : | |
| Connector Detail : |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 309.31(W)×173.99(H) mm. As a AH-IPS, Normally Black, Transmissive LCM product, LP140WF6-SPB6 can provides 700:1 transimissive contrast ratio, 80/80/80/80 (Min.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted WLED as it's backlight systerm which was placed as Edge light type, With LED Driver. LP140WF6-SPB6 utilizes eDP as it's signal inputting systerm, which connected by 30 pins Connector. It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of LP140WF6-SPB6 We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with LG Display or it's distributor. The above parameters are not from the datasheet, only as a reference, please use with caution!
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
