Product Details:
|
| MODEL NUMBER: | LC490EGH-FKM1 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 49 Inch | BRIGHTNESS: | 500CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 3840(3)×2160, UHD, 90PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | 3840x2160 Industrial Lcd Panel,500cd/m2 Industrial Lcd Panel,90PPI Lcd Video Panel |
||
| Basic Detail : | Manufacturer | Model Name | LC490EGH-FKM1 | |
|---|---|---|---|---|
| Panel Type | a-Si TFT-LCD , LCM | Another Name | LC490EGH (FK)(M1) | |
| Panel Size | 49 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -20 ~ 60 °C |
| Basic Information : | Luminance | 500 cd/m² (Typ.) | Contrast Ratio | 1400 : 1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Good View at | Symmetry | Response Speed | 8/10 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Operating Mode | IPS, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.281; Wy:0.288 | Support Color | 1.07B (10-bit) |
| Color Temperature | 9966K | White Uniformity | 1.54 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 79% | sRGB | 100% coverage |
| Adobe RGB | 77% coverage | DCI-P3 | 82% coverage | |
| Rec.2020 | 59% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Pixel Features : | Number of Pixel | 3840(3)×2160 [UHD] | Arrangement | RGBW Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.09321×0.27963 mm | Pixel Pitch(W×H) | 0.27963×0.27963 mm [90PPI] | |
| Physical Size : | Active Viewing | 1073.78(W)×604(H) mm | Overall Dim. | 1095.6(W)×633.4(H) mm |
| Bezel Opening | 1079.8(W)×609.3(H) mm | Overall Depth | 15.5 (Typ.) mm | |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 16:9 | Shape Style | ||
| Other Detail : | Mass | 9.00/9.50Kgs (Typ./Max.) | Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Signal Electrical : | Input Current | 1.09/1.42A (Typ./Max.) | Input Voltage | 12.0V (Typ.) | ||
|---|---|---|---|---|---|---|
| Consumption | 13.8/18.0W (Typ./Max.) | Signal Interface | EPI | |||
| Interface Features : | Position | Physical Type | Connector | |||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| HRS | TF06L-60S-0.5SH | 2 pcs | 0.5 mm | 60 pins | ||
| Lamp Features: | Lamp Shape | - | Lamp Type | WLED | Position | Edge light type (Bottom side) |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | - | Life | 30K(Typ.) (Hours) | |
| Lamp Electrical : | Input Current | 109.3/115/120.8mA (Min./Typ./Max.) | Input Voltage | 107.2/111.0/118.8V (Min./Typ./Max.) | ||
| Consumption | 76.6/82W (Typ./Max.) | |||||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
| UJU | HS100-L08N-N62 | 1 pcs | 1.0 mm | 8 pins | BLE-8PINS-CCCNNNNA | |
| UJU | HS100-L08N-N62-A | 1 pcs | 1.0 mm | 8 pins | BLE-8PINS-ANNNNCCC | |
| Backlight Driver : | No | |||||
| Package Box : | Amount | Size (L×W×H) | Weight |
|---|---|---|---|
| 20 pcs / box | 1300×1140×825 mm | - |
