Product Details:
|
| MODEL NUMBER: | LM270WQ1-SDB3 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 27.0INCH | BRIGHTNESS: | 420CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 2560(RGB)×1440 (Quad-HD) 108PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | 108PPI IPS Lcd Display Panels,420cd/m2 NTSC Lcd Video Panel,2560×1440 Antiglare NEC TFT Display |
||
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| LM270WQ1-SDB3 | a-Si TFT-LCD , LCM | LM270WQ1 (SD)(B3) | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| 0 ~ 50 °C | -20 ~ 60 °C |
| Panel Size : | 27.0 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 2560(RGB)×1440, Quad-HD | RGB Vertical Stripe | 0.0777×0.2331 mm | 0.2331×0.2331 mm [108PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 596.736×335.664 mm | 601.7×340.7 mm | 630×376.13 mm | 16.36/21.9 (Typ./Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 16:9 (W : H) | Landscape type | Normal bezel | |
| Fixation : | Side mounting holes (14-M3) on left, right, up, down bezel | |||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 4.60Kgs (Typ.) | Glare (Haze 0%), Hard coating (2H), Antireflection | ||
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 420 cd/m² (Typ.) | H-IPS, Normally Black, Transmissive | 1000:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 89/89/89/89 (Typ.)(CR≥10) | Symmetry | 6.5/7.5 (Typ.)(Tr/Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| 6799K | 16.7M (8-bit) | X:0.308; Y:0.325 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 77% | 100% | 77% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 79% | 57% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Luminance Variation : | 1.43 (Max.)(13 points) | ||
| Signal Electrical : | Current Input | Voltage Input | Consumption | |||
|---|---|---|---|---|---|---|
| 900/1035mA (Typ./Max.) | 12.0V (Typ.) | 10.8/12.42W (Typ./Max.) | ||||
| Interface Features : | Position | Type | Interface | |||
| Connector | eDP (4 Lanes) | |||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| I-PEX | 20474-040E-11 | 1 pcs | 0.4 mm | 40 pins | ||
| molex | 53780-8606 | 1 pcs | 1.25 mm | 6 pins | ||
| molex | 53780-8604 | 1 pcs | 1.25 mm | 4 pins | ||
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type (Left and Right) | 6 strings | 6 strings | 39K(Min.) | - | |
| WLED Electrical : | Current Input | Voltage Input | Consumption | |||
| 36±5V | 75.6/80.15W (Typ./Max.) | |||||
| Interface Features : | Position | Type | WLED Driver | |||
| - | Connector | No | ||||
| Interface Detail | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| E&T | H401K-D12N-12B | 1 pcs | 2.0 mm | 12 pins | BLE-12PINS-ACACACACACAC | |
| Package Carton : | Amount | Weight | Carton Size |
|---|---|---|---|
| 7 pcs / box | - | 747×335×466 mm (L×W×H) |
