Product Details:
|
| MODEL NUMBER: | LM201WE2-SLA1 | BRAND: | LG. LCD |
|---|---|---|---|
| SIZE: | 20.1 Inch | BRIGHTNESS: | 470CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1680(RGB)×1050 [WSXGA+] 98PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | 1680×1050 IPS Lcd Display Panels,98PPI Lcd Video Panel,470cd/m2 Antiglare NEC TFT Display |
||
| Basic Information : | Brand Name | Model Name | Type | Model Alias |
|---|---|---|---|---|
| LM201WE2-SLA1 | a-Si TFT-LCD , LCM | LM201WE2 (SL)(A1) | ||
| Maximum Ratings : | RoHS | Operating Temperature | Storage Temperature | Vibration Level |
| 0 ~ 50 °C | -20 ~ 60 °C |
| Screen Size : | 20.1" | |||
|---|---|---|---|---|
| Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
| 1680(RGB)×1050, WSXGA+ | RGB Vertical Stripe | 0.086×0.258 mm | 0.258×0.258 mm [98PPI] | |
| Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
| 433.44×270.9 mm | 438.4×275.9 mm | 461.4×296.8 mm | 36.9 (Typ.) mm | |
| Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
| Flat Rectangle | 16:10 | Landscape type | Normal bezel | |
| Other Spec : | Mass | Panel Cover | Surface Treatment | |
| 2.68Kgs (Typ.) | - | Glare (Haze 0%) | ||
| Holes & Brackets : | Face mounting holes | |||
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 470 cd/m² (Typ.) | S-IPS, Normally Black, Transmissive | 1600:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| Symmetry | 89/89/89/89 (Typ.)(CR≥10) | 5/7 (Typ.)(Tr/Td), 6 (Typ.)(G to G) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 6485K | 16.7M (8-bit) | X:0.313; Y:0.329 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 73% | 95% | 76% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 76% | 54% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| White Uniformity : | 1.45 (Max.)(9 points) | ||
| Back-light Features: | Type | Position | Life(Hours) | Amount | Shape | Replacement |
|---|---|---|---|---|---|---|
| CCFL | Direct light type | 50K(Min.) | 10 pcs | Straight | - | |
| Interface Features : | CCFL Driver State | Physical Type | Interface Position | |||
| With Inverter | Connector | - | ||||
| Interface Detail | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| JST | S14B-PHA-SM3-TB | 1 pcs | 14 pins | 2.0 mm | ||
| CCFL Driver Electrical : | Input Voltage | Input Current | Power Consumption | |||
| 24.0±2.0V | 1.92/2.28A (Typ./Max.) | 46.1±4.6W | ||||
| Signal Electrical : | Input Voltage | Input Current | Power Consumption | |||
|---|---|---|---|---|---|---|
| 12.0V (Typ.) | 460/560mA (Typ./Max.) | 5.59/6.72W (Typ./Max.) | ||||
| Interface Features : | Signal Type | Physical Type | Interface Position | |||
| LVDS (2 ch, 8-bit) | Connector | - | ||||
| Interface Detail : | Brand Name | Model Name | Amount | Pins | Pin Pitch | Pin Configuration |
| UJU | IS100-L30B-C23 | 1 pcs | 30 pins | 1.0 mm | LVDS-30P2C8B-180C | |
| Package Box : | Amount | Weight | Size (L×W×H) |
|---|---|---|---|
| 6 pcs / box | - | 409×489×543 mm (L×W×H) |
