LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY

LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY
LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: LG Display
Certification: ISO9001
Model Number: LC650EQF-FHM2
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 100PCS
Contact Now

LC650EQF-FHM2 LG Display 65" 3840(RGB)×2160 400 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: LC650EQF-FHM2 BRAND: LG Display
SIZE: 65 Inch BRIGHTNESS: 400CD/M2
Lamp Type: WLED RESOLUTION: 3840(RGB)×2160 (UHD) 68PPI
VIEWING ANGLEG: 89/89/89/89 (Typ.)(CR≥10) TEMPERATURE RANGE: Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
High Light:

WLED Industrial TFT Display

,

Hard Coating Industrial TFT Display

,

Monochrome Industrial TFT Display

LG Display LC650EQF-FHM2 Application Details

Basic Information :
Brand

LC650EQF-FHM2Model
Type
a-Si TFT-LCD , LCM
Used For

65 inchScreen Size
Alias
LC650EQF (FH)(M2)
Environment :
Storage Temp.
-20 ~ 60 °C
Operating Temp.
0 ~ 50 °C



LG Display LC650EQF-FHM2 Mechanical Details

Pixel Features :
Resolution
3840(RGB)×2160, UHD
Dot Pitch(mm)
0.124×0.372 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.372×0.372 (H×V) [68PPI]
Mechanical Size :
Active Area(mm)
1428.48(H) × 803.52(V)
Bezel Area(mm)
1430.48(H) × 805.52(V)
Outline Dim.(mm)
1452.2(H) × 830(V)
Depth(mm)
30.4 (Max.)
Outline Features :
Form Style
Flat Rectangle
Shape Style

Aspect Ratio
16:9 (H:V)
Orientation
Landscape type
Other Spec :
Weight
21.4Kgs (Typ.)
Treatment
Antiglare (Haze 1%), Hard coating (3H)



LG Display LC650EQF-FHM2 Optical Details

Basic Information :
Luminance(cd/m²)
400 (Typ.)
Contrast Ratio
1400:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Min.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
5 (Typ.)(G to G); 8 (Typ.)(MPRT)
Color Performance :
White Coordinate
Wx:0.281; Wy:0.288
Display Colors
16.7M/1.07B (8-bit / 8-bit + Dithering)
Color Temperature
9966K
White Uniformity
1.54 (Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
71%
sRGB
95% coverage
Adobe RGB
72% coverage
DCI-P3
74% coverage
Rec.2020
53% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



LG Display LC650EQF-FHM2 Interface Detail

Signal Electrical :
Voltage Supply
12.0V (Typ.)
Current Supply
0.8/1.05A (Typ./Max.)
Consumption
9.5/12.4W (Typ./Max.)
Signal Type :
V-by-One 16 lane
Logic Voltage
-
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
JAE
FI-RE51S-HF
0.5 mm
51 pins
1 pcs

JAE
FI-RE41S-HF
0.5 mm
41 pins
1 pcs

YEONHO
20037WR-H05
2.0 mm
5 pins
1 pcs



LG Display LC650EQF-FHM2 Backlight Details

Backlight Features :
Type
WLED
Quantity
-
Position
Edge light type
Replacement
-
Shape
-
Life Time
30K(Min.) (Hours)
Lamp Electrical :
Voltage Supply
86.8±7V
Current Supply
180mA (Typ.)
Consumption
105W (Typ.)
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Quantity
Pin Configuration
UJU
HS100-L08N-N62
1.0 mm
8 pins
2 pcs

Backlight Driver :
No



LG Display LC650EQF-FHM2 Packing Details

Package Box : Quantity Weight Box Size
18 pcs / box - 1600×1140×1053 mm (L×W×H)



 FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
