Product Details:
|
| MODEL NUMBER: | LM215WF1-TLB1 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 21..5 Inch | BRIGHTNESS: | 300CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 1920(RGB)×1080 [FHD] 102PPI |
| VIEWING ANGLEG: | 85/85/80/80 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Highlight: | WLED Industrial TFT Display,Hard Coating Industrial TFT Display,Monochrome Industrial TFT Display |
||
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| LM215WF1-TLB1 | a-Si TFT-LCD , LCM | LM215WF1 (TL)(B1) | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| 0 ~ 50 °C | -20 ~ 60 °C |
| Panel Size : | 21.5 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 1920(RGB)×1080, FHD | RGB Vertical Stripe | 0.08275×0.24825 mm | 0.24825×0.24825 mm [102PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 476.64×268.11 mm | 479.84×271.31 mm | 495.6×292.2 mm | 11.9/17.0 (Typ./Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 16:9 (W : H) | Landscape type | Normal bezel | |
| Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features : | Panel Cover | Weight | Surface | |
| Pixel Features : | solution | Pixel Arrangement |
|---|
| Voltage Input | Consumption | |||||
| 700±105mA | 5.0V (Typ.) | 3.8/4.5/5.2W (Min./Typ./Max.) | ||||
| Interface Features : | Position | Type | Interface | |||
| Connector | LVDS (2 ch, 8-bit) | |||||
| Signal Interface : | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| HRS | MDF76LBRW-30S-1H | 1 pcs | 1.0 mm | 30 pins | LVDS-30P2C8B-160C | |
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| CCFL | Edge light type (Top and Bottom) | Straight | 4 pcs | 50K(Min.) | - | |
| CCFL Electrical : | Current Input | Voltage Input | Consumption | |||
| 2.5/7.5/8.0mA (Min./Typ./Max.) | 800±105V | 24.0/26.4W (Typ./Max.) | ||||
| Turn-on Voltage | Lamp Frequency | |||||
| 1250/1550V (Max.)(Ta=+25/0℃) | 40/70KHz (Min./Max.) | |||||
| Interface Features : | Position | Type | CCFL Driver | |||
| Connector | No | |||||
| Interface Detail | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| YEONHO | 35001HS-02LD | 4 pcs | 3.5 mm | 2 pins | BLL-2PINS-HL | |
| Package Carton : | Amount | Weight | Carton Size |
|---|---|---|---|
| 7 pcs / box | - | 370×320×580 mm (L×W×H) |
