Product Details:
|
| MODEL NUMBER: | LM215UH1-SPA1 | BRAND: | LG Display |
|---|---|---|---|
| SIZE: | 21..5 Inch | BRIGHTNESS: | 540CD/M2 |
| Lamp Type: | WLED | RESOLUTION: | 4096(RGB)×2304 218PPI |
| VIEWING ANGLEG: | 89/89/89/89 (Typ.)(CR≥10) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | WLED Industrial TFT Display,Hard Coating Industrial TFT Display,Monochrome Industrial TFT Display |
||
| Basic Information : | Brand | Model | LM215UH1-SPA1 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 21.5" | Alias | LM215UH1 (SP)(A1) | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 50 °C |
| Pixel Features : | Resolution | 4096(RGB)×2304 | Dot Pitch(mm) | 0.03874×0.11622 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.11622×0.11622 (H×V) [218PPI] | |
| Mechanical Size : | Active Area(mm) | 476.04(H) × 267.77(V) | Bezel Area(mm) | 480(H) × 273.1(V) |
| Outline Dim.(mm) | 500.4(H) × 293.5(V) | Depth(mm) | 13.8 (Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | Normal bezel |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Mounting : | Rear mounting holes (7-M3) | |||
| Other Spec : | Weight | 1.72Kgs (Typ.) | Treatment | Hard coating (2H), Antireflection |
| Basic Information : | Luminance(cd/m²) | 540 (Typ.) | Contrast Ratio | 1200:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | IPS, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 14 (Typ.)(G to G) | |
| Color Performance : | White Coordinate | X:0.313; Y:0.329 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6485K | White Uniformity | 1.58 (Max.)(13 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 99% | sRGB | 100% coverage |
| Adobe RGB | 89% coverage | DCI-P3 | 99% coverage | |
| Rec.2020 | 74% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Signal Electrical : | Voltage Supply | 10.0V (Typ.) | Current Supply | 510/637mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Consumption | 5.1/6.37W (Typ./Max.) | |||||
| Signal Type : | eDP (4 Lanes) | Signal Voltage | - | |||
| Interface Features : | Position | Type | Connector | |||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| LS Mtron | GT05Q-30S-H10-MN | 1 pcs | 30 pins | 0.5 mm | EDP-30P4L-050B | |
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type (Bottom side) |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 30K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 39.9/42.7/45.5V (Min./Typ./Max.) | Current Supply | 140/145mA (Typ./Max.) | ||
| Consumption | 23.9/25.5W (Typ./Max.) | |||||
| Interface Features : | Position | Type | Connector | |||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| YEONHO | 10035WR-H06D | 1 pcs | 6 pins | 1.0 mm | BLE-6PINS-CCAACC | |
| Backlight Driver : | No | |||||
| Package Box : | Quantity | Weight | Box Size |
|---|---|---|---|
| 14 pcs / box | - | 572×372×360 mm (L×W×H) |
