N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY

N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY
N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: INNOLUX
Certification: ISO9001
Model Number: N133HCE-EAA
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 1500PCS
Contact Now

N133HCE-EAA Innolux 13.3" 1920(RGB)×1080 250 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: N133HCE-EAA BRAND: INNOLUX
SIZE: 13.3 Inch BRIGHTNESS: 250CD/M2
Lamp Type: WLED RESOLUTION: 1920(RGB)×1080 [FHD] 166PPI
VIEWING ANGLEG: 85/85/85/85 (Typ.)(CR≥10) TEMPERATURE RANGE: Erating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
High Light:

NTSC Lcd Video Panel

,

Antiglare NEC TFT Display

,

Capacitive TFT Touch Panel

Innolux N133HCE-EAA Application Details

Basic Info :
Panel Brand

N133HCE-EAAPanel Model
Diagonal Size
13.3"
Application

a-Si TFT-LCD , LCMPanel Type
Model Alias
CMN1375
Reliability :
Operating Temp.
0 ~ 50 °C
Storage Temp.
-20 ~ 60 °C



Innolux N133HCE-EAA Mechanical Details

Pixel Features :
Pixel Format
1920(RGB)×1080, FHD
Dot Pitch
0.051×0.153 mm (H×V)
Configuration
RGB Vertical Stripe
Pixel Pitch
0.153×0.153 mm (H×V) [166PPI]
Mechanical Size :
Display Area
293.76×165.24 mm (H×V)
Bezel Area
-
Outline Dim.
300.26×187.72 mm (H×V)
Outline Depth
2.83/3.0 (Typ./Max.) mm
Outline Features :
Form Factor
Flat Rectangle
Orientation
Landscape type
Aspect Ratio
16:9 (H:V)
Shape Style
Slim (PCBA Flat, T≤3.2mm)
Holes & Brackets :
Without
Other Features :
Weight
248.5/260g (Typ./Max.)
Surface
Antiglare, Hard coating (3H)



Innolux N133HCE-EAA Optical Details

Basic Information :
Brightness
250 cd/m² (Typ.)
Contrast Ratio
700:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Optical Mode
AAS, Normally Black, Transmissive
Viewing Direction
Symmetry
Response Time
14/11 (Typ.)(Tr/Td) ms
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
262K (6-bit)
Color Temperature
6485K
Uniformity
1.25/1.54 (Typ./Max.)(9 points)
1931 Color Gamlt :
NTSC Ratio
47%
sRGB
66% coverage
Adobe RGB
50% coverage
DCI-P3
49% coverage
Rec.2020
35% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)



Innolux N133HCE-EAA Backlight Details

Back-light Features :
Lamp Type
WLED
Amount
9S3P
Life Time
15K(Min.) (Hours)
Replacement
-
Lamp Shape
-
Position
Edge light type
Interface Features :
Type
Included in panel signal interface
Position
-
Lamp Driver
With LED Driver
Driver Electrical :
Voltage Input
5.0/12.0/21.0V (Min./Typ./Max.)
Current Input
149/180/192mA (Min./Typ./Max.)
Consumption
2.4W (Max.)



Innolux N133HCE-EAA Interface Detail

Signal Systerm :
eDP (2 Lanes)
Logic Voltage
-
Signal Electrical :
Voltage Input
3.3V (Typ.)
Current Input
206/226mA (Typ./Max.)
Consumption
0.75W (Max.)
Interface Features :
Type
Connector
Position
Connector Detail :
Brand
Model
Pin Pitch
Pins
Amount
Configuration
I-PEX
20455-030E-76
0.5 mm
30 pins
1 pcs
EDP-30P2L-020A



Innolux N133HCE-EAA Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
40 pcs / box - 540×450×320 mm



FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
