Product Details:
|
| BRAND: | Kyocera | MODEL NUMBER: | TG035QVLQAANN-GN00 |
|---|---|---|---|
| SIZE: | 3.5INCH | RESOLUTION: | 320×240RGB |
| BRIGHTNESS: | 1200 Cd/m² (Typ.) | Signal Type: | Parallel RGB (1 Ch, 8-bit) + SPI , 50 Pins FPC |
| Backlight: | WLED , 60K Hours , No Driver | Max. Ratings: | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Highlight: | WLED Industrial TFT Display,Hard Coating Industrial TFT Display,Monochrome Industrial TFT Display |
||
| Basic Information : | Brand | Model | TG035QVLQAANN-GN00 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For |
|
|
| Screen Size | 3.5" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 80 °C | Operating Temp. | -20 ~~ 70 °C |
| RoHS | Vibration | - |
| Pixel Features : | Resolution | 320(LCR)×240, QVGA | Dot Pitch(mm) | 0.0735×0.2205 (H×V) |
|---|---|---|---|---|
| Pixel Format | LCR Vertical Stripe | Pixel Pitch(mm) | 0.2205×0.2205 (H×V) [115PPI] | |
| Mechanical Size : | Active Area(mm) | 70.56(H) × 52.92(V) | Bezel Area(mm) | 72.26(H) × 54.62(V) |
| Outline Dim.(mm) | 76.9(H) × 63.9(V) | Depth(mm) | 4.90±0.3 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 40.0g | Treatment | - |
| Basic Information : | Luminance(cd/m²) | 1200 (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 80/80/80/60 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive | |
| Best View on | 12 o'clock | Response(ms) | 8/22 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.310; Y:0.310 | Display Colors | Grayscale (6-bit) |
| Color Temperature | 6852K | White Uniformity | - | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (180°) |
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 8.0/11.3mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | Parallel RGB (1 ch, 8-bit) + SPI | Signal Voltage | 0≤VIL≤0.3VDD; 0.8VDD≤VIH≤VDD | |||
| Interface Features : | Position | - | Type | FPC | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 50 pins | 0.5 mm | ||||
| Backlight Features: | Shape | 2 strings | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 60K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 12.5/13.3V (Typ./Max.) | Current Supply | 15mA (Typ.) | ||
| Interface Features : | Position | - | Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
