Product Details:
|
| MODEL NUMBER: | TCG085WVLQDPNN-GN00 | BRAND: | Kyocera |
|---|---|---|---|
| SIZE: | 8.5INCH | RESOLUTION: | 800×480RGB |
| BRIGHTNESS: | 400 Cd/m² (Typ.) | Interface Type: | CMOS (1 Ch, 6-bit) , 40 Pins Connector |
| Light Source: | WLED , 70K Hours , W/O Driver | TEMPERATURE RANGE: | Operating Temperature: -20 ~ 70 °C |
| Highlight: | WLED Industrial TFT Display,WVGA Industrial Lcd Panel |
||
| Basic Information : | Brand | Model | TCG085WVLQDPNN-GN00 | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For |
|
|
| Screen Size | 8.5" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 80 °C | Operating Temp. | -20 ~~ 70 °C |
| RoHS | Vibration | - |
| Pixel Features : | Resolution | 800(RGB)×480, WVGA | Dot Pitch(mm) | 0.077×0.231 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.231×0.231 (H×V) [109PPI] | |
| Mechanical Size : | Active Area(mm) | 184.8(H) × 110.88(V) | Bezel Area(mm) | 187.4(H) × 113.5(V) |
| Outline Dim.(mm) | 210(H) × 134(V) | Depth(mm) | 8.7/9.2 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 15:9 (H:V) | Orientation | Landscape type | |
| Mounting : | Face mounting holes (2 pcs) | |||
| Other Spec : | Weight | 310g | Treatment | Glare (Haze 0%) |
| Basic Information : | Luminance(cd/m²) | 400 (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | AWV, Normally Black, Transmissive | |
| Best View on | Symmetry | Response(ms) | 12/18 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.310; Y:0.325 | Display Colors | 262K (6-bit) |
| Color Temperature | 6685K | White Uniformity | - | |
| 1931 Color Gamlt : | NTSC Ratio | 50% | sRGB | 70% coverage |
| Adobe RGB | 53% coverage | DCI-P3 | 52% coverage | |
| Rec.2020 | 38% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (U/D, L/R) |
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 200/260mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | CMOS (1 ch, 6-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| HRS | FH33-40S-0.5SH(10) | 1 pcs | 40 pins | 0.5 mm | ||
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 70K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 29.2/32.0V (Typ./Max.) | Current Supply | 60mA (Typ.) | ||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JST | PHR-4 | 1 pcs | 4 pins | 2.0 mm | BLE-4PINS-AACC | |
| Backlight Driver : | No | |||||
