Product Details:
|
| BRAND: | Kyocera | MODEL NUMBER: | T-51963GD035J-MLW-AJN |
|---|---|---|---|
| SIZE: | 3.5INCH | RESOLUTION: | 240×320RGB |
| Type: | A-Si TFT-LCD, LCM | Interface Type: | CMOS (1 Ch, 6-bit) |
| Light Source: | WLED , W/O Driver | TEMPERATURE RANGE: | Operating Temperature: -20 ~ 70 °C |
| Highlight: | WLED Industrial TFT Display,LCD Industrial TFT Display |
||
| Basic Info : | Panel Brand | Panel Model | T-51963GD035J-MLW-AJN | |
|---|---|---|---|---|
| Diagonal Size | 3.5" | Application | ||
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | -20 ~ 70 °C | Storage Temp. | -30 ~ 70 °C |
| RoHS State | Vibration Rating | - |
| Pixel Features : | Pixel Format | 240(RGB)×320 [QVGA] | Dot Pitch | 0.0745×0.2235 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.2235×0.2235 mm (H×V) [113PPI] | |
| Mechanical Size : | Display Area | 53.64×71.52 mm (H×V) | Bezel Area | - |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Portrait type |
| Aspect Ratio | 3:4 (H:V) | Shape Style |
| Basic Information : | Brightness | - | Contrast Ratio | 70:1 (Typ.) (Transmissive) 8:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Viewing Angle | 40/40/40/40 (Typ.)(CR≥10) | Optical Mode | TN, Normally White, Transflective | |
| Viewing Direction | - | Response Time | 30/50 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.320; Wy:0.350 | Color Numbers | 262K (6-bit) |
| Color Temperature | 6022K | White Uniformity | 1.43 (Max.)(5 points) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
| 3D Type | - | Reflectance | 20% (Typ.) |
| Frame Frequency : | 60Hz |
|---|---|
| Time Controller (T-CON) : | Embedded T-CON |
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Edge light type | |
| Interface Features : | Type | Included in panel signal interface | Position | - | Lamp Driver | No |
| Signal Systerm : | CMOS (1 ch, 6-bit) | Logic Voltage | ||
|---|---|---|---|---|
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
