Product Details:
|
| MODEL NUMBER: | T-51963GD035J-MLW-AGN | BRAND: | Kyocera |
|---|---|---|---|
| RESOLUTION: | 240×320RGB | SIZE: | 3.5INCH |
| BRIGHTNESS: | 130 Cd/m² (Typ.) | Signal Interface: | CMOS (1 Ch, 6-bit) , 50 Pins FPC |
| Lamp Type: | WLED , 5K Hours , Without Driver | TEMPERATURE RANGE: | Operating Temp.: -20 ~ 70 °C |
| High Light: | WLED Industrial TFT Display,LCD Industrial TFT Display |
||
| Basic Information : | Brand | Model | T-51963GD035J-MLW-AGN | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 3.5" | Alias | - | |
| Environment : | Storage Temp. | -30 ~~ 70 °C | Operating Temp. | -20 ~~ 70 °C |
| RoHS | Vibration | - |
| Pixel Features : | Resolution | 240(RGB)×320, QVGA | Dot Pitch(mm) | 0.0745×0.2235 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.2235×0.2235 (H×V) [113PPI] | |
| Mechanical Size : | Active Area(mm) | 53.64(H) × 71.52(V) | Bezel Area(mm) | - |
| Outline Dim.(mm) | 65(H) × 86.2(V) | Depth(mm) | 4.0 (Typ.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 3:4 (H:V) | Orientation | Portrait type | |
| Touch Panel : | Touch Points | 1 point | Touch Panel | 4-wire Resistive Touch |
| TP Controller | Without touch controller | Touch Signal | - | |
| Other Spec : | Weight | 50.0g (Max.) | Treatment | - |
| Basic Information : | Luminance(cd/m²) | 130 (Typ.) | Contrast Ratio | 70:1 (Typ.) (Transmissive) 5:1 (Typ.) (Reflective) |
|---|---|---|---|---|
| Viewing Angle | 40/40/40/40 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transflective | |
| Best View on | - | Response(ms) | 30/50 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.320; Y:0.350 | Display Colors | 262K (6-bit) |
| Color Temperature | 6022K | White Uniformity | 1.43 (Max.)(5 points) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
| 3D Type | - | Reflectance | 20% (Typ.) |
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (U/D, L/R) |
| Time Controller (T-CON) : | Embedded T-CON |
| Signal Electrical : | Voltage Supply | 3.3/5.0/16.0/-12.0V (Typ.)(VDDD/VDDA/VGH/VGL) | Current Supply | 1.6/8.0/0.05/0.05mA (Typ.)(IDDD/IDDA/IGH/IGL) | ||
|---|---|---|---|---|---|---|
| Signal Type : | CMOS (1 ch, 6-bit) | Signal Voltage | 0≤VIL≤0.8V; 2.7V≤VIH≤3.6V | |||
| Interface Features : | Position | - | Type | FPC | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 50 pins | 0.5 mm | ||||
| Backlight Features: | Shape | - | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | 5K(Min.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 19.2/21.0V (Typ./Max.) | Current Supply | 15/20mA (Typ./Max.) | ||
| Consumption | 0.384W (Typ.) | |||||
| Interface Features : | Position | - | Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
