Product Details:
|
| BRAND: | Kyocera | MODEL NUMBER: | KG057QV1CB-G00 |
|---|---|---|---|
| SIZE: | 5.7INCH | RESOLUTION: | 320×240RGB |
| BRIGHTNESS: | 180 Cd/m² (Typ.) | Signal Interface: | Parallel Data , 20 Pins Connector |
| Lamp Type: | 1 Pcs CCFL , 58K Hours | TEMPERATURE RANGE: | Operating Temp.: 0 ~ 60 °C |
| Highlight: | CCFL CSTN LCD Panel,VGA Lcd Video Panel |
||
| Basic Information : | Brand | Model | KG057QV1CB-G00 | |
|---|---|---|---|---|
| Type | LCM FSTN-LCD | Used For | ||
| Screen Size | 5.7" | Alias | - | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 60 °C |
| RoHS | Vibration | - |
| Pixel Features : | Resolution | 320×240, QVGA | Dot Pitch(mm) | 0.360×0.360 (H×V) |
|---|---|---|---|---|
| Pixel Format | Rectangle | Pixel Pitch(mm) | 0.360×0.360 (H×V) [70PPI] | |
| Mechanical Size : | Active Area(mm) | 115.2(H) × 86.4(V) | Bezel Area(mm) | 119.4(H) × 90.6(V) |
| Outline Dim.(mm) | 144(H) × 104.8(V) | Depth(mm) | 10.8/15.3 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Touch Panel : | Touch Points | 1 point | Touch Panel | 4-wire Resistive Touch |
| TP Controller | Without touch controller | Touch Signal | - | |
| Mounting : | Rear mounting poles (4-Φ2.6) | |||
| Other Spec : | Weight | 220g (Typ.) | Treatment | Antiglare, Hard coating (2H) |
| Basic Information : | Luminance(cd/m²) | 180 (Typ.) | Contrast Ratio | 10:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥2) | Display Mode | STN, Black/White (Negative), Transmissive | |
| Best View on | - | Response(ms) | 210/130 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.310; Y:0.300 | Display Colors | Monochrome |
| Color Temperature | 6989K | White Uniformity | - |
| Frame Rate : | 75Hz |
|---|---|
| Reverse Scan : | No |
| Driving Method : | Duty: 1/240 |
| Signal Electrical : | Voltage Supply | 3.3/5.0V (Typ.)(VDD) | Current Supply | 41.5/28.5mA (Typ.)(3.3V/5.0V)(IDD) | ||
|---|---|---|---|---|---|---|
| Signal Type : | Parallel Data | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| Kyocera Elco | 08-6210-020-340-800 | 1 pcs | 20 pins | 0.5 mm | PD-20P1C4B-010A | |
| Backlight Features: | Shape | - | Type | CCFL | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 1 pcs | Life Time | 58K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 330V (Typ.) | Current Supply | 3.0/4.0/6.0mA (Min./Typ./Max.) | ||
| Frequency | 40/100KHz (Min./Max.) | Startup Voltage | 530/795V (Max.)(Ta=+25/0℃) | |||
| Consumption | 1.32W (Typ.) | |||||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JST | BHR-03VS-1 | 1 pcs | 3 pins | 4.0 mm | BLL-3PINS-HNL | |
