Product Details:
|
| BRAND: | Kyocera | MODEL NUMBER: | KG038QV0AN-G00 |
|---|---|---|---|
| SIZE: | 3.8INCH | RESOLUTION: | 320×240RGB |
| Lamp Type: | No B/L | Signal Interface: | Parallel Data (4-bit) , 20 Pins FPC |
| Panel Type: | FSTN-LCD , LCM | TEMPERATURE RANGE: | Operating Temp.: 0 ~ 60 °C |
| High Light: | CCFL CSTN LCD Panel,VGA Lcd Video Panel |
||
| Basic Information : | Brand | Model | KG038QV0AN-G00 | |
|---|---|---|---|---|
| Type | LCM FSTN-LCD | Used For | ||
| Screen Size | 3.8" | Alias | - | |
| Environment : | Storage Temp. | -20 ~~ 60 °C | Operating Temp. | 0 ~~ 60 °C |
| RoHS | Vibration |
| Pixel Features : | Resolution | 320×240, QVGA | Dot Pitch(mm) | 0.240×0.240 (H×V) |
|---|---|---|---|---|
| Pixel Format | Rectangle | Pixel Pitch(mm) | 0.240×0.240 (H×V) [105PPI] | |
| Mechanical Size : | Active Area(mm) | 76.78(H) × 57.58(V) | Bezel Area(mm) | 78.8(H) × 59.6(V) |
| Outline Dim.(mm) | 102(H) × 76(V) | Depth(mm) | 2.6/3.4 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 30.0g (Typ.) | Treatment | Glare (Haze 0%) |
| Basic Information : | Luminance(cd/m²) | - | Contrast Ratio | 40:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥2) | Display Mode | STN, Black/White (Negative), Transmissive | |
| Best View on | - | Response(ms) | 380/120 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | - | Display Colors | Monochrome |
| Dispaly Performance : | Outdoor Visibility | No | Transmissivity | 20% (Typ.)(with Polarizer) |
| Frame Rate : | 75Hz |
|---|---|
| Reverse Scan : | No |
| Driving Method : | Duty: 1/240 |
| Signal Electrical : | Voltage Supply | 3.3/5.0V (Typ.)(VDD) | Current Supply | 34/24mA (Typ.)(3.3V/5.0V)(IDD) | ||
|---|---|---|---|---|---|---|
| Signal Type : | Parallel Data (4-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | FPC | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 20 pins | 0.5 mm | ||||
| Backlight Features: | Shape | - | Type | No B/L | Position | - |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | - |
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
Contact Person: Ms. Shirley
Tel: +8613352991648
Fax: 852-3-1828535
