G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY

G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY
G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY

Large Image :  G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY

Product Details:
Place of Origin: JAPAN
Brand Name: INNOLUX
Certification: ISO9001
Model Number: G070Y2-L01
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: STANDARD PACKING
Delivery Time: 1-2 DAYS
Payment Terms: TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability: 1500PCS

G070Y2-L01 INNOLUX 7.0" 800(RGB)×480 500 cd/m² INDUSTRIAL LCD DISPLAY

Description
MODEL NUMBER: G070Y2-L01 BRAND: INNOLUX
SIZE: 7.0INCH BRIGHTNESS: 500CD/M2
Lamp Type: WLED RESOLUTION: 800(RGB)×480 [WVGA] 133PPI
VIEWING ANGLEG: 70/70/60/60 (Typ.)(CR≥10 TEMPERATURE RANGE: Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 M/s²)
High Light:

IPS Lcd Display Panels

,

RGB Vertical LCD Display

,

LVDS TFT LCD Module

Innolux G070Y2-L01 Application Features

Basic Information : Brand Model Type Model Alias
  G070Y2-L01 a-Si TFT-LCD , LCM -
Reliability : RoHS Operating Temperature Storage Temperature Vibration Resistance
  -30 ~ 85 °C -40 ~ 95 °C 3.0G (29.4 m/s²)



Innolux G070Y2-L01 Mechanical Features

Panel Size : 7.0 inch
Pixel Features : Resolution Pixel Arrangement Dot Pitch (W×H) Pixel Pitch (W×H)
800(RGB)×480, WVGA RGB Vertical Stripe 0.0635×0.1905 mm 0.1905×0.1905 mm [133PPI]
Mechanical Size : Active Area (W×H) Bezel Area (W×H) Outline Dimension (W×H) Outline Depth
152.4×91.44 mm 154.6×93.64 mm 165×104 mm 9.53±0.5 mm
Outline Features : Form Style Aspect Ratio Orientation Shape Style
Flat Rectangle 15:9 (W : H) Landscape type
Fixation : Without
Other Features : Panel Cover Weight Surface
- 147/162g (Typ./Max.) Antiglare, Hard coating (3H)



Innolux G070Y2-L01 Optical Features

Basic Information : Brightness Operating Mode Contrast Ratio
500 cd/m² (Typ.) TN, Normally White, Transmissive 600:1 (Typ.) (Transmissive)
Viewing Angle(L/R/U/D) Viewing Direction Response Speed
70/70/60/60 (Typ.)(CR≥10) - 5/11 (Typ.)(Tr/Td) (ms)
Dispaly Color : Color Temperature Color Amount White color Chromaticity
6485K 262K/16.2M (6-bit / 6-bit + FRC) X:0.313; Y:0.329
1931 Color Gamlt : NTSC Ratio sRGB Coverage Adobe RGB Coverage
74% 97% 75%
DCI-P3 Coverage Rec.2020 Coverage Remarks
77% 56% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Luminance Variation : 1.25/1.40 (Typ./Max.)(5 points)



Innolux G070Y2-L01 Interface Features

Signal Electrical : Current Input Voltage Input Consumption
170/204mA (Typ./Max.) 3.3V (Typ.) 0.56W (Typ.)
Interface Features : Position Type Interface
- Connector LVDS (1 ch, 6/8-bit)
Signal Interface : Brand Model Amount Pin Pitch Pins Pin Assignment
STARCONN 076B20-0048RA-G4 1 pcs 1.25 mm 20 pins LVDS-20P1C8B-160A



Innolux G070Y2-L01 Backlight Features

Backlight Features: Type Position Shape Amount  Life(Hours) Replacement
WLED Edge light type (Bottom side) Array - 50K(Min.) -
Interface Features : Position Type WLED Driver
- Connector With LED Driver
Interface Detail Brand Model Amount Pin Pitch Pins Pin Assignment
UNE LM123S004HTF13 1 pcs 1.25 mm 4 pins
Driver Electrical : Current Input Voltage Input Consumption
0.25A (Typ.) 12.0±1.2V 3.15W (Typ.)



Innolux G070Y2-L01 Packing Features

Package Carton : Amount Weight Carton Size
34 pcs / box - 465×362×314 mm (L×W×H)
