Product Details:
|
| MODEL NUMBER: | KCB104VG2CG-G20 | BRAND: | Kyocera |
|---|---|---|---|
| SIZE: | 10.4INCH | RESOLUTION: | 640×480RGB |
| Screen Type: | LCM , CSTN-LCD | Signal Type: | Parallel Data (8-bit) Connector |
| High Light: | WLED FSTN LCD display,WLED Industrial TFT Display |
||
| Basic Detail : | Manufacturer | Model Name | KCB104VG2CG-G20 | |
|---|---|---|---|---|
| Panel Type | CSTN-LCD , LCM | Another Name | - | |
| Panel Size | 10.4 inch | Designed For | ||
| Maximum Ratings : | OP Temperature | - | ST Temperature | - |
| Vibration Level | - | RoHS |
| Basic Information : | Luminance | - | Contrast Ratio | - |
|---|---|---|---|---|
| Good View at | - | Response Speed | 16/80 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 45/45/35/20 (Typ.)(CR≥2) | Operating Mode | STN, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | Color |
| Color Temperature | 6638K | White Uniformity |
| Pixel Features : | Number of Pixel | 640(RGB)×480 [VGA] | Arrangement | RGB Vertical Stripe |
|---|---|---|---|---|
| Dot Pitch(W×H) | 0.110×0.330 mm | Pixel Pitch(W×H) | 0.330×0.330 mm [76PPI] | |
| Physical Size : | Active Viewing | 211.2(W)×158.4(H) mm | Overall Dim. | - |
| Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio(W:H) | 4:3 | Shape Style |
| Refresh Rate : | 75Hz |
|---|---|
| Reverse Scan : | No |
| Signal Electrical : | Input Current | - | Input Voltage | |||
|---|---|---|---|---|---|---|
| Consumption | - | Signal Interface | Parallel Data (8-bit) | |||
| Interface Features : | Position | - | Physical Type | Connector | ||
| Lamp Features: | Lamp Shape | Straight | Lamp Type | CCFL | Position | Edge light type (Top and Bottom) |
|---|---|---|---|---|---|---|
| Exchange | - | Amount | 2 pcs | Life | - | |
| Backlight Driver : | Optional | |||||
