Product Details:
|
| MODEL NUMBER: | DMF5005NY-LY | BRAND: | Kyocera |
|---|---|---|---|
| SIZE: | 5.2INCH | RESOLUTION: | 240×64RGB |
| BRIGHTNESS: | 45 Cd/m² | Lamp Type: | STN-LCD, LCM |
| TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C | Interface: | 8-bit Parallel , 22 Pins Pad |
| High Light: | WLED FSTN LCD display,WLED Industrial TFT Display |
||
| Pixel Features : | Resolution | 240×64 | Dot Pitch(mm) | 0.53×0.53 (H×V) |
|---|---|---|---|---|
| Pixel Format | Rectangle | Pixel Pitch(mm) | 0.53×0.53 (H×V) [47PPI] | |
| Mechanical Size : | Active Area(mm) | 127.16(H) × 33.88(V) | Bezel Area(mm) | 132.0(H) × 39.0(V) |
| Outline Dim.(mm) | 180(H) × 65(V) | Depth(mm) | 17.6 | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | >3:1 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | 170g (Max.) | Treatment |
| Basic Information : | Luminance(cd/m²) | 45 (Min.) | Contrast Ratio | 7:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 32/32/36/33 (Typ.)(CR≥2) | Display Mode | STN, Yellow/Green (Positive), Transmissive | |
| Best View on | 6 o'clock | Response(ms) | 160/160 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | - | Display Colors | Monochrome (1-bit) |
OPTREX DMF5005NY-LY Electronics Details
| Frame Rate : | 70Hz |
|---|---|
| Driver IC : | Built-in T6963C-0101 |
| Driving Method : | Duty: 1/64 , Bias: 1/9 |
| Signal Electrical : | Voltage Supply | 5.0V (Typ.)(VCC) | Current Supply | 7.0/20.0mA (Typ./Max.)(ICC) | ||
|---|---|---|---|---|---|---|
| Signal Type : | 8-bit parallel | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Pad | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| 1 pcs | 22 pins | 2.5 mm | ||||
| Backlight Features: | Shape | - | Type | YG-LED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | - | Life Time | - | |
| Lamp Electrical : | Voltage Supply | 4.1±0.3V | Current Supply | |||
| Backlight Driver : | No | |||||
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
