Product Details:
|
| MODEL NUMBER: | TX54D13VC0CAA | BRAND: | HITACHI |
|---|---|---|---|
| SIZE: | 21.3 Inch | RESOLUTION: | 1600(RGB)×1200 [UXGA] 94PPI |
| BRIGHTNESS: | 430 Cd/m² (Typ.) | TEMPERATURE RANGE: | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| High Light: | Antiglare NEC TFT Display,QVGA Square Tft Display,VGA Lcd Video Panel |
||
| Basic Info : | Panel Brand |  |
Panel Model | TX54D13VC0CAA |
|---|---|---|---|---|
| Diagonal Size | 21.3" | Application |
|
|
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | - | |
| Reliability : | Operating Temp. | 0 ~ 50 °C | Storage Temp. | -20 ~ 60 °C |
| RoHS State | - | Vibration Rating | 1.5G (14.7 m/s²) |
| Pixel Features : | Pixel Format | 1600(RGB)×1200 [UXGA] | Dot Pitch | 0.090×0.270 mm (H×V) |
|---|---|---|---|---|
| Configuration | RGB Vertical Stripe | Pixel Pitch | 0.270×0.270 mm (H×V) [94PPI] | |
| Mechanical Size : | Display Area | 432×324 mm (H×V) | Bezel Area | - |
| Outline Dim. | 460×362 mm (H×V) | Outline Depth | 25.0±0.5 mm | |
| Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
| Aspect Ratio | 4:3 (H:V) | Shape Style | ||
| Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel | |||
| Other Features : | Weight | 3.45/4.00Kgs (Typ./Ma×.) | Surface | Antiglare |
| Basic Information : | Brightness | 300 cd/m² (Typ.) | Contrast Ratio | 900:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Optical Mode | IPS-Pro, Normally Black, Transmissive | |
| Viewing Direction | Symmetry | Response Time | 11/14 (Typ.)(Tr/Td) (ms) | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Color Numbers | 16.7M (8-bit) |
| Color Temperature | 6638K | White Uniformity | 1.33 (Max.)(9 points)  |
|
| 1931 Color Gamut : | NTSC Ratio | 72% | sRGB | 99% coverage |
| Adobe RGB | 75% coverage | DCI-P3 | 75% coverage | |
| Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Frame Frequency : | 60Hz Reverse Scan :
| No |
|---|
| Back-light Features: | Lamp Shape | Straight | Lamp Type | CCFL | Life Time | - |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | 6 pcs | Position | Edge light type (Top and Bottom) | |
| Lamp Electrical : | Voltage Input | 800V (Typ.) | Current Input | 3.0/6.5/7.0mA (Min./Typ./Max.) | ||
| Frequency | 40/54/65MHz (Min./Typ./Max.) | Kick-off Voltage | 1500/1750V (Min./Max.)(Ta=0℃) | |||
| Interface Features : | Type | Connector | Position | - | Lamp Driver | No |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JST | XHP-7 | 2.5 mm | 7 pins | 2 pcs | BLL-7PINS-HNNHNNH | |
| JST | BHR-03VS-1 | 4.0 mm | 3 pins | 2 pcs | BLL-3PINS-LLL | |
| Signal Systerm : | LVDS (2 ch, 8-bit) | Logic Voltage | - | |||
|---|---|---|---|---|---|---|
| Signal Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | - | ||
| Interface Features : | Type | Connector | Position | - | ||
| Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| JAE | FI-X30S-HF | 1.0 mm | 30 pins | 1 pcs | LVDS-30P2C8B-160A | |
whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 432(W)×324(H) mm, outline size of 460(W)×362(H)×25.5(D) mm, with surface treament of Antiglare, net weight of 3.45/4.00Kgs (Typ./Ma×.). As a IPS-Pro, Normally Black, Transmissive LCM product, TX54D13VC0CAA can provides 300 cd/m² display brightness 900:1 transimissive contrast ratio, 85/85/85/85 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 11/14 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 99% (sRGB). This product adopted 6 pcs CCFL as it's backlight systerm which was placed as Edge light type (Top and Bottom), external backlight driver is additionally needed. TX54D13VC0CAA utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 12.0V (Typ.). It's typical vertical frame rate (Fv) is 60Hz. For more latest product detail of TX54D13VC0CAA We strongly recommend that you should refer to datasheet listed on Panelook.com or contact with HITACHI or it's distributor.
